产品描述

GE燃气轮机控制板DS3800DADB具有一根永久连接到板上的20针带状电缆和3针型连接器。GE燃气轮机控制板DS3800DADB还装有用于连接各种组件的端子。该板高 3.5 英寸，长 6 英寸。它设计用于安装在驱动器内部的板架中，为多种类型的板和其他设备留出空间。这些板是可选设备，可为现场所需的处理类型提供不同的功能。

20 针带状电缆提供信号以命令电路板执行某些处理功能。一些信号从其他电路板发送到电路板进行处理。其他信号被传输到其他电路板和组件。由于带状电缆较短且永久连接到电路板，因此在断开带状电缆时采用良好做法非常重要。

切勿抓住电路板并将带状电缆从其连接的连接器中拉出。此操作可以轻松地将细线与带状电缆末端的连接器断开。您会注意到带状电缆提供的支撑很少，因此必须小心。要断开带状电缆，请抓住带状电缆末端的连接器，然后将其从板上的连接器中拉出。偶尔检查带状电缆连接器和带状电缆之间是否有磨损迹象。请注意电线是否似乎已从连接器中拔出，如果发生这种情况，请更换带状电缆。

DS3800DADB 用于安装在驱动器内部的板架中

Product description

The GE gas turbine control board DS3800DADB has a 20-pin ribbon cable permanently attached to the board and a 3-pin connector. The GE gas turbine control board DS3800DADB also contains terminals for connecting various components. The board is 3.5 inches high and 6 inches long. It is designed to be mounted in a plate rack inside the drive, leaving room for multiple types of boards and other devices. These boards are optional devices that provide different functions for the type of processing required in the field.

The 20-pin ribbon cable provides the signal to command the board to perform certain processing functions. Some signals are sent from other boards to the board for processing. Other signals are transmitted to other boards and components. Since ribbon cables are short and permanently attached to the circuit board, it is important to adopt good practices when disconnecting ribbon cables.

Never grab the circuit board and pull the ribbon cable out of the connector to which it is attached. This operation easily disconnects the thin wire from the connector at the end of the ribbon cable. You will notice that ribbon cables provide little support, so care must be taken. To disconnect the ribbon cable, grab the connector at the end of the ribbon cable and pull it out of the connector on the board. Occasionally check for signs of wear between the ribbon cable connector and the ribbon cable. Note if the wire seems to have been pulled out of the connector, and if this happens, replace the ribbon cable.
