产品描述

GE励磁电源板DS3800DEPB具有1根20针带状电缆和5个10针连接器。GE LCI 励磁器控制板DS3800DECA1B1B还装有 4 个用于添加组件的端子和 2 个微调器电阻器。

10 针连接器的一些 ID 是 JA-RUN、CAL1B 和 JB-COM。由于 5 针连接器中有 10 个，因此确定要连接到每个连接器的正确带状电缆非常重要。如果安装主板但未将带状电缆连接到正确的连接器，则需要关闭驱动器并将带状电缆插入正确的连接器。这将降低驱动器的生产率，并为在周边地区使用驱动器的操作员带来不便。

相反，请在每根电缆上标记它所连接的连接器的 ID。它将使更换板的安装快速简便。

20 针带状电缆无法从主板上拔下，它用作与驱动器的连接。请务必确保它完全固定在连接器中。为此，请用力按压连接器顶部以确保连接牢固。如果看到连接器之间的空间，则可能表示某些引脚未完全连接。

DS3800DEPB 励磁电源板 5个10针连接器

Product description

The GE excitation power board DS3800DEPB has one 20-pin ribbon cable and five 10-pin connectors. The GE LCI exciter control board DS3800DECA1B1B also houses four terminals for adding components and two trimmer resistors.

Some ids for 10-pin connectors are JA-RUN, CAL1B, and JB-COM. Since there are 10 out of 5 pin connectors, it is important to determine the correct ribbon cable to connect to each connector. If the motherboard is installed but the ribbon cable is not connected to the correct connector, you need to close the driver and plug the ribbon cable into the correct connector. This will reduce the productivity of the drive and inconvenience operators who use the drive in the surrounding area.

Instead, mark each cable with the ID of the connector to which it is connected. It will make the installation of the replacement plate quick and easy.

The 20-pin ribbon cable cannot be unplugged from the motherboard and is used as a connection to the drive. Make sure it is fully secured in the connector. To do this, press firmly on the top of the connector to ensure a secure connection. If you see space between connectors, it may indicate that some pins are not fully connected.
