GE DS3800DFPF 具有 3800 个蓝色电阻器

GE DS3800DFPF 具有 3800 个蓝色电阻器

产品描述

该DS3800DFPF是通用电气（GE）的Mark IV Speedtronics系列的一部分。DS3800DFPF具有 3800 个蓝色电阻器。每个电阻器上都有不同的颜色，以显示可以流过每个电阻的能量。还有七个浅蓝色二极管和两个浅灰色二极管。还有两个大的银色二极管和两个大的黑色二极管。 DS3800DFPF上还有两个长十脚电容器。

DS3800DFPF还具有两个红色矩形电容器。该板有八个接收引脚（金），用于将两个板连接在一起。这些是有编号的。该DS3800DFPF还具有四个EEPROM，用于保存电路板编程。EEPROM无法重新编程。DS3800DFPF还具有两个带状线束。沿板上边缘的那个更大。顶部有一个浅蓝色的塑料连接器，将其固定在板上，另一端有一个黑色端子。

第二个色带线束较小，有一个黑色塑料连接器，将其连接到电路板，还有一个小型黑色连接器连接到另一个板。电路板本身是淡绿色的.板上的每一块都可以通过其深金属绿色标记来识别。电路板编号DS<>DFPF与通用电气的标签一起印在板上，下面有美国标签，以显示其制造地点。

GE DS3800DFPF 具有 3800 个蓝色电阻器

Product description

The DS3800DFPF is part of General Electric's (GE) Mark IV Speedtronics family. The DS3800DFPF has 3,800 blue resistors. Each resistor has a different color on it to show how much energy can flow through each resistor. There are also seven light blue diodes and two light gray diodes. There are also two large silver diodes and two large black diodes. There are also two long ten-pin capacitors on the DS3800DFPF.

The DS3800DFPF also features two red rectangular capacitors. The board has eight receiving pins (gold) that are used to join the two boards together. These are numbered. The DS3800DFPF also has four EEPROMs for saving board programming. EEPROM cannot be reprogrammed. The DS3800DFPF also has two ribbon harnesses. The one along the top edge of the board is bigger. There is a light blue plastic connector at the top that holds it to the board, and a black terminal at the other end.

The second ribbon harness is smaller and has a black plastic connector that connects it to the board, and a small black connector that connects to the other board. The circuit board itself is light green. Each piece on the board can be identified by its deep metallic green markings. The board number DS<>DFPF is printed on the board along with a GE label, with a US label underneath to show where it was manufactured.
