GE DS3800DGRD1C1A Mark IV涡轮机控制系列创建的辅助板

GE DS3800DGRD1C1A Mark IV涡轮机控制系列创建的辅助板

产品描述

DS3800DGRD1C1A是GE为其Mark IV涡轮机控制系列创建的辅助板。

DS3800DGRD1C1A板具有多个不同尺寸的电容器，包括 100 伏和 80 伏电容器。辅助板的一半被几个黑色电位计或可调电阻占据，通常标有最低和最高设置（以欧姆为单位）。DS3800DGRD1C1A辅助卡具有一系列带有蓝色跳线的跳线引脚，允许操作员更改电路板的功能。DS3800DGRD1C1A板上有各种不同颜色的小条带电阻器和二极管，以及许多固体电阻器和二极管。主板侧面有黑色连接器端口。主板在两个连接器端口之间有两个标有 SW1 和 SW2 的开关（一个红色和一个黑色）。DS3800DGRD1C1A在跳线旁边有一排测试点。几个方形电容器位于电路板的一侧。

Speedtronic Mark IV系统是在早期的Speedtronic Mark I和Mark II系统开发的基础上创建的。早期的Mark系列基于涡轮机控制自动化，涡轮机的排序和保护已经发展了几十年。Mark IV系统是数十年来创造和完善新技术的产物。Mark IV 涡轮机系统的创建是为了满足控制涡轮机的要求，包括在速度和负载控制的要求范围内控制燃料。

GE DS3800DGRD1C1A Mark IV涡轮机控制系列创建的辅助板

Product description

The DS3800DGRD1C1A is an auxiliary board created by GE for its Mark IV turbine control family.

The DS3800DGRD1C1A board has several capacitors of different sizes, including 100 volt and 80 volt capacitors. Half of the auxiliary board is occupied by several black potentiometers or adjustable resistors, usually labeled with minimum and maximum Settings (in ohms). The DS3800DGRD1C1A auxiliary card features a series of jumper pins with blue jumpers that allow the operator to change the board's functionality. The DS3800DGRD1C1A board has a variety of small strip resistors and diodes in different colors, as well as many solid resistors and diodes. There are black connector ports on the side of the mainboard. The motherboard has two switches labeled SW1 and SW2 (one red and one black) between the two connector ports. The DS3800DGRD1C1A has a row of test points next to the jumper. Several square capacitors are located on one side of the board.

The Speedtronic Mark IV system was created based on the earlier development of the Speedtronic Mark I and Mark II systems. The early Mark series is based on the automation of turbine control, sequencing and protection of turbines that have evolved over decades. The Mark IV system is the product of decades of creating and perfecting new technology. The Mark IV turbine system was created to meet the requirements of controlling the turbine, including controlling the fuel within the requirements of speed and load control.
