DS3800DLBA1A1A 负载平衡辅助板 GE 具有 12 个端子

DS3800DLBA1A1A 负载平衡辅助板 GE 具有 12 个端子

产品描述

GE 负载平衡辅助板DS3800DLBA1A1A具有 12 个端子，用于将其他组件连接到电路板，以及 16 个单线引脚连接器。GE负载平衡辅助板DS3800DLBA1A1A还装有7个微调电阻和1个嵌入在板上的晶体管-晶体管逻辑元件。

板上的 12 个端子使合格的服务人员或技术人员能够在不修改电路板设计的情况下向电路板添加组件。重要的是，只有合格的人员才能添加组件，因为存在损坏驱动器中的主板或其他组件的风险。此外，服务人员和安装人员必须知道如何操作测试设备以及如何事先对其进行校准。

12 个端子使您能够将组件添加到电路板上的各种电路中，因此您必须知道要将组件添加到哪个电路以及将哪些 2 个端子连接到电路。您最多可以在 6 个端子之间添加 2 个组件。要添加组件，请使用螺丝刀松开端子顶部的螺钉。将引线滑入端子并拧紧端子螺钉。不要过度拧紧螺钉。

使用测试设备验证添加组件后是否实现了预期的结果。当主板从驱动器中卸下并且服务人员或安装人员佩戴静态保护腕带时，请务必执行此活动。将板子放在防静电袋的顶部，在表面干净的桌子或桌子上工作。

DS3800DLBA1A1A 负载平衡辅助板 GE 具有 12 个端子

Product description

The GE load balancing auxiliary board DS3800DLBA1A1A has 12 terminals for connecting other components to the board, as well as 16 single-wire pin connectors. The GE load balancing auxiliary board DS3800DLBA1A1A also houses seven trimbler resistors and a transistor-transistor logic element embedded on the board.

The 12 terminals on the board enable qualified service personnel or technicians to add components to the board without modifying the board design. It is important that only qualified personnel should add components as there is a risk of damaging the motherboard or other components in the drive. In addition, service personnel and installers must know how to operate the test equipment and how to calibrate it beforehand.

The 12 terminals enable you to add components to various circuits on the board, so you have to know which circuit to add the component to and which 2 terminals to connect to the circuit. You can add up to 2 components between 6 terminals. To add components, use a screwdriver to loosen the screw at the top of the terminal. Slide the lead into the terminal and tighten the terminal screw. Do not over-tighten the screws.

Use a test device to verify that the expected results were achieved after adding the component. Be sure to perform this activity when the motherboard is removed from the drive and the servicer or installer is wearing a static protection wristband. Place the board on top of the anti-static bag and work on a table or table with a clean surface.

DS3800DLBA1A1A 负载平衡辅助板 GE 具有 12 个端子
