产品描述

GE燃气轮机控制板DS3800DMEB1B1C设计用于快速安装在驱动器中。该板的一端有一个模块化连接器，另一端有一个固定杆。GE燃气轮机控制板DS1DMEB3800B1C还装有1个电容器和15个微调电阻器。该板装有 2 个带刻度盘设置的电位计和 2 个指示灯 LED。它还填充了测试点。

GE燃气轮机控制板DS3800DMEB1B1C由于固定杆，很容易从驱动器上拆下。主板上的模块化连接器适合主板机架后部的模块化连接器。当您将模块化连接器压在一起时，将建立信号和电源连接，为电路板提供电力。模块化连接器还传输控制信号。控制信号由电路板接收进行处理。然后，经过处理后，它们被发送到驱动器中的其他板进行进一步处理。但是，由于电路板易于拆卸，因此对技术人员有触电的危险。

在开始更换过程之前，驱动器已从所有电源中卸下。驱动器从多个电源接收电源。电流可以是直流或交流电流。最好与工程师或其他知识渊博的人员协商电源以及如何将其从驱动器中移除。

DS3800DMEB1B1C燃气轮机控制板 有1个电容器

Product description

The GE gas turbine control board DS3800DMEB1B1C is designed for quick installation in the drive. The board has a modular connector at one end and a fixed rod at the other end. The GE gas turbine control board DS1DMEB3800B1C also houses 1 capacitor and 15 trimmer resistors. The board is equipped with 2 potentiometers with dial Settings and 2 indicator leds. It also populates the test points.

GE gas turbine control board DS3800DMEB1B1C is easily removed from the drive due to the fixed rod. Modular connectors on the motherboard Fit the modular connectors at the rear of the motherboard rack. When you press the modular connectors together, a signal and power connection will be established to provide power to the board. Modular connectors also transmit control signals. The control signal is received by the circuit board for processing. Then, after processing, they are sent to other boards in the drive for further processing. However, because the circuit board is easy to disassemble, there is a risk of electric shock to technicians.

The drive is removed from all power supplies before starting the replacement process. The driver receives power from multiple sources. The current can be direct current or alternating current. It is best to negotiate with an engineer or other knowledgeable person about the power supply and how to remove it from the drive.
