产品描述

GE燃气轮机子板DS3800HCMC1A1B具有模块化连接器，用于连接到驱动器和固定杆，用于将板固定在驱动器中。GE燃气轮机子板DS3800HCMC1A1B还装有14个跳线，1个琥珀色和2个红色指示灯LED。该板还具有 2 个 34 针连接器，以及多个电容器和电阻器。

板上的指示灯 LED 位于该位置，因此当电路板安装在驱动机架中时，操作员可以一目了然地看到 LED。LED 位于 2 个 34 针连接器之间。当一个或两个红色 LED 亮起时，表示发生了错误。当琥珀色 LED 亮起时，表示已发出警告。有关错误和警告的详细信息，可以运行驱动器上可用的诊断工具。这些工具提供驱动器活动的历史记录以及有关组件性能的详细信息。例如，如果发生任何错误，您可以阅读报告并了解错误发生的时间并了解错误的原因。

诊断工具还包括任何跳闸条件。跳闸条件是可能损坏驱动器的情况。某些跳闸条件是由过热情况引起的。也就是说，热量在驱动器内部积聚。如果安装驱动器的房间太热，则可能会发生这种情况。如果驱动器中的热量由于通风口堵塞而无法逸出，也会发生这种情况。

GE DS3800HCMC1A1B  燃气轮机子板 具有模块化连接器

Product description

The GE gas turbine subboard DS3800HCMC1A1B has modular connectors for connection to the drive and a retaining rod for securing the board in the drive. The GE gas turbine sub-board DS3800HCMC1A1B is also fitted with 14 jumpers, 1 amber and 2 red indicator leds. The board also features 2 34-pin connectors, as well as multiple capacitors and resistors.

The indicator LED on the board is located in this location, so the operator can see the LED at a glance when the board is mounted in the drive rack. The LED is located between 2 34-pin connectors. When one or two red leds light up, an error has occurred. When the amber LED lights up, a warning has been issued. For more information about errors and warnings, you can run the diagnostic tools available on the drive. These tools provide a history of drive activity as well as detailed information about component performance. For example, if anything goes wrong, you can read the report and know when the error occurred and understand the cause of the error.

The diagnostic tool also includes any trip conditions. Trip conditions are conditions that can damage a drive. Some tripping conditions are caused by overheating conditions. That is, heat builds up inside the drive. This can happen if the room in which the drive is installed is too hot. This can also happen if the heat in the drive cannot escape due to blocked vents.
