DS3800HDRA  驱动器/接收器板 GE 有模块化连接器

DS3800HDRA  驱动器/接收器板 GE 有模块化连接器

产品描述

GE Line 驱动器/接收器板DS3800HDRA具有模块化连接器，用于连接到驱动器和固定杆，用于将板固定在驱动器中。GE线路驱动器/接收器板DS3800HDRA还装有2个跳线和多个电容器。该板还具有 2 个 40 针连接器，可从板前部访问。

当电路板安装在驱动器中时，操作员可以访问 2 个 40 针连接器。但是，只有在驱动器已断开所有电源时，才应触摸连接到接头的任何电缆。

断开驱动器电源需要熟悉驱动器安装的人员确认已卸下所有电源。驱动器具有多个电流源，只有熟悉安装的人才能知道电源以及如何断开电源。在触摸开发板之前，请使用功能齐全的测试设备确认所有电源均已断开。

熟悉与驱动器关联的紧急电源关闭设备。在紧急情况下，关闭可以断开驱动器的所有电源。重要的是，2 名技术人员始终在场维修驱动器。如果一名技术人员遇到紧急情况，另一名技术人员可以寻求帮助、关闭电源或协助另一名技术人员。

在开始安装之前，请检查驱动器周围的区域是否有安全条件。确保地板干燥，没有油和碎屑。如果地板上有水分，请先清理水。如果再次出现湿气，您可能需要安装除湿机，以使地板保持干燥。

DS3800HDRA  驱动器/接收器板 GE 有模块化连接器

Product description

The GE Line driver/receiver board DS3800HDRA features modular connectors for connection to the drive and a retaining rod for securing the board in the drive. The GE line driver/receiver board DS3800HDRA also houses 2 jumpers and multiple capacitors. The board also has 2 40-pin connectors that can be accessed from the front of the board.

When the board is mounted in the drive, the operator has access to 2 40-pin connectors. However, any cable connected to the connector should only be touched if the driver has disconnected all power.

Disconnect the power supply from the driver. Ensure that all power supplies are removed by personnel familiar with driver installation. The driver has multiple current sources, and only someone familiar with installation can know the power supply and how to disconnect it. Before touching the development board, use a fully functional test device to confirm that all power is disconnected.

Be familiar with emergency power shutdown devices associated with drives. In an emergency, shutting down can disconnect all power to the drive. It is important that 2 technicians are always present to repair the drive. If one technician is in an emergency, another technician can call for help, turn off the power, or assist another technician.

Before starting the installation, check the area around the drive for safe conditions. Make sure the floor is dry and free of oil and debris. If there is moisture on the floor, please clean the water first. If moisture reappears, you may need to install a dehumidifier to keep the floor dry.

DS3800HDRA  驱动器/接收器板 GE 有模块化连接器
