GE DS3800HDRA1B1B 线路驱动器/接收板

GE DS3800HDRA1B1B 线路驱动器/接收板

GE 线路驱动器/接收板 DS3800HDRA1B1B 具有用于连接驱动器的模块化连接器和用于将电路板固定在驱动器中的固定杆。GE 线路驱动器/接收板 DS3800HDRA1B1B 还装有 2 个跳线和多个电容器。该板还有 2 个 40 针连接器，可从板的正面访问。

电路板上的另一个组件是晶体管到晶体管逻辑 (TTL) 设备。它用作集成电路之间的接口逻辑。

该板的 1 端装有模块化连接器。模块化连接器设计用于与驱动器中板架背面的另一个模块化连接器连接。2 个模块化连接器会合并为许多信号和电源连接提供连接。当电路板从驱动器中移除时，连接将在服务人员不干预的情况下中断。也就是说，只需移除电路板即可结束信号和电源连接。模块化连接便于板接收到的命令信号进行处理。模块化连接还为电路板提供了向驱动器中的其他电路板发送命令信号的方法。在正常处理过程中，电路板多次发送和接收信号以控制电机和运动部件。

在电路板的另一侧是固定杆。它们适合板架上的插槽并将板锁定在机架中。它们防止电路板移动以保护组件。它们还保持模块化连接器之间的连接。

GE DS3800HDRA1B1B 线路驱动器/接收板

The GE line driver/receiver board DS3800HDRA1B1B has a modular connector for connecting the driver and a fixing rod for securing the circuit board to the driver. The GE line driver/receiver board DS3800HDRA1B1B also has 2 jumpers and multiple capacitors. The board also has 2 40-pin connectors that can be accessed from the front of the board.

Another component on the board is a transistor-to-transistor logic (TTL) device. It serves as the interface logic between integrated circuits.

One end of the board is equipped with a modular connector. The modular connector is designed to connect to another modular connector on the back of the chassis in the driver. Two modular connectors are combined to provide connections for many signal and power connections. When the board is removed from the drive, the connection will be broken without the intervention of the service personnel. In other words, simply remove the circuit board to end the signal and power connection. The modular connection facilitates the processing of command signals received by the board. Modular connections also provide a way for the board to send command signals to other boards in the driver. During normal processing, the circuit board sends and receives signals several times to control the motor and moving parts.

On the other side of the board is the holding rod. They fit into the slots in the board frame and lock the board in the frame. They prevent the board from moving to protect the components. They also maintain connections between modular connectors.
