产品描述

GE Fish 处理器板DS3800HFPE1D1C具有用于连接到驱动器的模块化连接器和用于将板固定在驱动器中的固定杆。GE Fish 处理器板DS3800HFPE1D1C还配备了 3 个跳线和多个电容器。该板有 1 个 40 针连接器，可从板正面访问。它还在电路板表面安装了测试点和 1 个 40 针连接器。

电路板上的另一个组件是晶体管到晶体管逻辑 （TTL） 器件。

GE Fish 处理器板DS3800HFPE1D1C上提供了几个测试点。测试点被分配 ID，以帮助服务人员找到用于测试特定电路的测试点。一些测试点 ID 是 DOC、RST 和 TP3。有一个服务文档，描述了每个测试点的用途，并描述了每个测试点测试的信号。提供该信息后，服务人员可以找到用于测试的测试点。

服务人员必须手头有一个全功能的测试设备。它必须具有与测试设备兼容的探针。探头必须处于良好状态。确保所有绝缘层完好无损，并且电缆引线没有磨损或电线暴露。将电路板放在干净且无湿气的工作台或桌子上。如果桌子上有水，请使用干净的布擦干表面。在电路板下方放置防静电材料。这可以是压扁的袋子或其他材料。

DS3800HFPE1D1C 处理器板 多个电容器

Product description

The GE Fish processor board DS3800HFPE1D1C has a modular connector for attaching to the drive and a retaining rod for attaching the board to the drive. The GE Fish processor board DS3800HFPE1D1C is also equipped with 3 jumpers and multiple capacitors. The board has a 40-pin connector that can be accessed from the front of the board. It also has test points and a 40-pin connector mounted on the board surface.

Another component on the board is a transistor-to-transistor logic (TTL) device.

Several test points are available on the GE Fish processor board DS3800HFPE1D1C. Test points are assigned ids to help service personnel find test points for testing specific circuits. Some test point ids are DOC, RST, and TP3. There is a service document that describes the purpose of each test point and describes the signals that each test point tests. Once this information is provided, the server can find the test point for testing.

Service personnel must have a fully functional test device on hand. It must have probes that are compatible with the test equipment. The probe must be in good condition. Make sure all insulation is intact and that the cable leads are not frayed or the wires exposed. Place the circuit board on a clean, moisture-free workbench or table. If there is water on the table, dry the surface with a clean cloth. Place anti-static material under the circuit board. This can be a squished bag or other material.

DS3800HFPE1D1C 处理器板 多个电容器
