DS3800HFXA1F1D 控制器 具有一个模块化连接器

DS3800HFXA1F1D 控制器 具有一个模块化连接器

GE继电器输出板DS200TCRAG1ACC装有30个插入式继电器。它还有4个34针连接器和4个12针连接器。分配给34针连接器的id是JOR.JOSJOT和JO 分配给12针连接器的id是JS3JS4JS5和JS6由于GE继电器输出板

DS200TCRAG1ACC上有多个连接器，因此必须遵循指南，以确保您可以快速将电缆连接到替换板上的正确连接器。在开始更换之前，请确保你知道驱动电流紧急切断装置的位置。

此外，您必须了解如何操作关闭装置，并确认其处于良好的工作状态，熟悉传动装置安装的人员将获得有关电源和紧急切断的详细信息。下一步是验证硬盘周围区域的地板是否干净，没有湿气或积水，使用清洁剂清除地板上的油污。你还应该移除所有未接地的双头电源线，因为有触电的危险。

DS3800HFXA1F1D 控制器 具有一个模块化连接器

The GE relay output board DS200TCRAG1ACC contains 30 plug-in relays. It also has four 34-pin connectors and four 12-pin connectors. The ids assigned to the 34-pin connector are JOR.JOSJOT and JO The ids assigned to the 12-pin connector are JS3JS4JS5 and JS6 due to the GE relay output board

There are multiple connectors on the DS200TCRAG1ACC, so the guidelines must be followed to ensure that you can quickly connect the cable to the correct connector on the replacement board. Before starting the replacement, make sure you know the location of the drive current emergency cutoff device.

In addition, you must know how to operate the shut-off device and confirm that it is in good working order, and people familiar with transmission installation will have detailed information on power supply and emergency cut-off. The next step is to verify that the floor in the area around the hard drive is clean and free of moisture or standing water, and use a cleaner to remove the oil from the floor. You should also remove all ungrounded double-ended power cords because of the risk of electric shock.

DS3800HFXA1F1D 控制器 具有一个模块化连接器
