DS3800NEPX1A1A PLC模块卡件

DS3800NEPX1A1A PLC模块卡件

GE点火电路板DS3800NEPX1A1A的每个角上有一个孔，用于用螺钉将电胳板固定到变频器内部。该板有4个支座，用于连接子卡。子卡提供了额外的处理、连接器和功能。

电路板上装有多个晶体管-晶体管逻辑器件。GE点火电路板DS38OONEPX1A1A也装有13个红色指示灯LED和1个琥珀色指示灯LED。该板还有一个用于电可擦除可编程只读存储器(EEPROM)模块的插座。该板j还配有多个跳线和2个34引脚连接器。

如果您在GE点火电路板DS38OONEPX1A1A上安装了子卡，则必须额外考虑额外的重量和体积会使安装更加困难。当您将板插入驱动器时，请用两只手握住板，并清楚地看到驱动器内部，这样可以避免撞到板或损坏驱动器中的其他组件。

DS3800NEPX1A1A PLC模块卡件

The GE ignition circuit board DS3800NEPX1A1A has a hole in each corner for fastening the electric plate to the inside of the frequency converter with screws. The board has four supports for connecting subcards. The daughter card provides additional processing, connectors, and functionality.

Multiple transistor-transistor logic devices are installed on the circuit board. The GE ignition circuit board DS38OONEPX1A1A also has 13 red indicator leds and 1 amber indicator LED. The board also has a socket for an electrically erasable programmable read-only memory (EEPROM) module. The board j also comes with multiple jumpers and 2 34-pin connectors.

If you have a subcard installed on the GE ignition board DS38OONEPX1A1A, the additional weight and volume that must be taken into account will make installation more difficult. When you insert the board into the drive, hold the board with both hands and see the inside of the drive clearly so as to avoid hitting the board or damaging other components in the drive.
