产品描述

GE烧制电路板DS3800NFCD1K1C在每个角落都有1个孔，用于用螺钉将电路板连接到驱动器内部。该板装有 4 个支架，用于连接子卡。子卡提供额外的处理、连接器和功能。该板装有多个晶体管-晶体管逻辑器件。

GE点火电路板DS3800NFCD1K1C还装有13个红色指示灯LED和1个琥珀色指示灯LED。该板还具有 1 个用于电可擦除可编程只读存储器 （EEPROM） 模块的插座。该板还装有多个跳线和 2 个 34 针连接器。

34 针连接器位于电路板的 1 个边缘，因此带状电缆不会干扰电路板上的组件。也就是说，带状电缆可以远离电路板并沿着驱动器的侧面布线，而不是穿过电路板表面。34 针连接器具有固定闩锁，可防止带状电缆意外断开。但是，固定闩锁需要一些特殊考虑。在将带状电缆连接到连接器之前，必须一次将固定闩锁摆到一边。然后，您可以将带状电缆连接到板上的连接器。要固定带状电缆，请旋转带状电缆上的固定闩锁，直到它们卡入到位。

DS3800NFCD1K1C GE 印刷电路板

Product description

The GE fired circuit board DS3800NFCD1K1C has 1 hole in each corner for attaching the board to the inside of the driver with screws. The board is equipped with four brackets for connecting subcards. Subcards provide additional processing, connectors, and functionality. The board is equipped with a plurality of transistor-transistor logic devices.

The GE ignition circuit board DS3800NFCD1K1C also has 13 red indicator leds and 1 amber indicator LED. The board also has a socket for an electrically erasable programmable read-only memory (EEPROM) module. The board is also equipped with multiple jumpers and two 34-pin connectors.

The 34-pin connector is located on 1 edge of the board, so the ribbon cable does not interfere with the components on the board. That is, the ribbon cable can be located away from the board and along the side of the driver, rather than across the board surface. The 34-pin connector has a fixed latch to prevent accidental disconnection of the ribbon cable. However, fixing latches requires some special considerations. Before connecting the ribbon cable to the connector, the fixing latch must be swung to one side at a time. You can then connect the ribbon cable to the connector on the board. To secure the ribbon cables, rotate the retaining latches on the ribbon cables until they snap into place.
