产品描述

DS3800NFCF1C1C是GE为Mark IV系统制造的PCB。Mark IV是为蒸汽和燃气轮机控制而设计的。Mark IV可以使涡轮机系统在安全参数范围内工作，还可以自动执行启动和关闭等程序。

该DS3800NFCF1C1C由42个集成电路组成。这包括上/下二进制计数器、触发器和8位静态MOS RAM，带单电源和+5 V电源。它有二十一个晶体管，十五个LED（十四个红色和一个琥珀色）和两个跳线。DS3800NFCF1C1C设计为接受辅助板 （DS3800DFCF），安装后，DS3800NFCF1C1C可以访问另外五个跳线和三个电流表。辅助板由四个尼龙引脚支撑，并由 <> 个板对板连接器锁定到位。

DS3800NFCF1C1C对齐标记为 A 到 L。它是工厂钻孔的，为用户提供安装选项。它沿一个边缘设计有两个插入开关。这些标记为“休息”和“步骤”。电路板上有三个连接器，允许DS3800NFCF1C1C与其他 PCB 通信.这包括一个 10 针垂直公连接器以及两个沿一个短边放置的 （218A4637-P4 0027） 连接器。

DS3800NFCF1C1C有 8542 个 TP 测试点。它由多个不同值的金属膜电阻器和多个 2 +/-0022 M/E 200 <>V 电容器构成。

DS3800NFCF1C1C由42个集成电路组成

Product description

DS3800NFCF1C1C is a PCB manufactured by GE for the Mark IV system. The Mark IV is designed for steam and gas turbine control. The Mark IV enables turbine systems to operate within safe parameters and automatically performs procedures such as start-up and shutdown.

The DS3800NFCF1C1C is composed of 42 integrated circuits. This includes up/down binary counters, flip-flops, and 8-bit static MOS RAM with a single power supply and a +5 V power supply. It has twenty-one transistors, fifteen leds (fourteen red and one amber), and two jumpers. The DS3800NFCF1C1C is designed to receive an auxiliary board (DS3800DFCF), and when installed, the DS3800NFCF1C1C has access to an additional five jumpers and three ammeters. The auxiliary board is supported by four nylon pins and is locked into place by <> board-to-board connectors.

DS3800NFCF1C1C The alignment is labeled A through L. It is factory drilled and provides installation options for the user. It is designed with two insert switches along an edge. These are labeled "breaks" and "steps." There are three connectors on the board that allow the DS3800NFCF1C1C to communicate with other PCBS. This includes a 10-pin vertical male connector and two (218A4677-P40027) connectors placed along a short side.

DS3800NFCF1C1C has 8542 TP test points. It consists of a number of metal film resistors of different values and a number of 2 +/-0022 M/E 200 <>V capacitors.
