DS3800NFCF1J1E是GE开发的涡轮控制燃烧板

DS3800NFCF1J1E是GE开发的涡轮控制燃烧板

DS3800NFCF1J1E是GE开发的涡轮控制燃烧板

产品描述

DS3800NFCF1J1E是GE开发的涡轮控制燃烧板。 它适合 Mark IV 系列，专为燃气轮机和蒸汽轮机控制而设计。Mark IV也可用于空气、燃料和水排放控制，有助于保持安全的运行条件，并允许用户自动执行一些涡轮机系统例程，例如关闭和冷却。

DS3800NFCF1J1E具有以下规格：

它有对齐标记（A-L）并在工厂钻孔。

它有两个按钮开关。这些标记为“步骤”和“重置”。

它有两组 LED。一组位于左上角，由七个红色 LED 组成。另一个位于左下角，由七个红色 LED 和一个琥珀色 LED 组成。

它有两个跳线开关。

它在每个边缘都有分组的晶体管。有二十一个晶体管。

测试点往往平行于电路板的边缘。有二十九个测试点。

它由各种二极管、电阻器和电容器构成，包括 8542 +/- 0022 M/e 200V 电解电容器。电阻器往往是金属膜电阻器。

它具有 42 个集成电路，包括晶体振荡器、8 位静态 MOS RAM 芯片、负边沿触发触发器和 4 位上/下计数器。

DS3800NFCF1J1E是GE开发的涡轮控制燃烧板

Product description

The DS3800NFCF1J1E is a turbo-controlled combustion panel developed by GE. It fits the Mark IV series and is designed for gas turbine and steam turbine control. The Mark IV can also be used for air, fuel and water discharge control, helping to maintain safe operating conditions and allowing users to automate some turbine system routines, such as shutdown and cooling.

DS3800NFCF1J1E has the following specifications:

It has an alignment mark (A-L) and is drilled in the factory.

It has two button switches. These are labeled "Steps" and "Reset."

It has two sets of leds. One set is located in the upper left corner and consists of seven red leds. The other is located in the lower left corner and consists of seven red leds and one amber LED.

It has two jumper switches.

It has grouped transistors at each edge. There are twenty-one transistors.

The test point is often parallel to the edge of the board. There are 29 test sites.

It consists of a variety of diodes, resistors and capacitors, including 8542 +/ -0022 M/e 200V electrolytic capacitors. Resistors are often metal film resistors.

It features 42 integrated circuits, including a crystal oscillator, an 8-bit static MOS RAM chip, a negative edge trigger trigger, and a 4-bit up/down counter.
