该产品是Speedtronic Mark ⅣV涡轮控制系列中的一个组件。它是由通用电气公司制造的。DS380ONFEXIBIA是一款故障探测器显示电路板。几十年来，Mark lV系列一直被用来为燃气和蒸汽涡轮机提供安全性和功能性。

DS38OONFEXIBIA有一个跨越电路板左边缘的长连接器端口。九(9)个红色led，也称为发光二极管，位于电路板的右边缘。led下方是十五(15)个测试点。这使用户能够确保电路板正常工作。DS3800NFEXBIA上遍布三十八(38)个集成电路。每个集成电路都包含非常小的电阻、二极管和电容。位于DS3800NFMC1F1D左侧的是十九(19)个晶体管。晶体管之间是各种其他元件。有不同颜色的电阻，二极管和电容。

下面是一排带状电阻，旁边是两(2)个带状电阻和两个带状电容。沿着DS380ONFEXIBIA的上边缘列出的是字母A到，在连接器端口旁边的左边缘是数字10到80乘以10。卡片右侧有更多带状电阻、实心红色电阻和带状电容。

DS380ONFEXIBIA GE印刷电路板

The product is a component of the Speedtronic Mark IV V turbine control family. It's made by General Electric. The DS380ONFEXIBIA is a fault detector display board. The Mark lV series has been used for decades to provide safety and functionality for gas and steam turbines.

The DS38OONFEXIBIA has a long connector port that spans the left edge of the board. Nine (9) red leds, also known as light-emitting diodes, are located on the right edge of the board. Below the led are fifteen (15) test points. This enables the user to ensure that the board is working properly. The DS3800NFEXBIA is spread over thirty-eight (38) integrated circuits. Each integrated circuit contains very small resistors, diodes, and capacitors. Located to the left of the DS3800NFMC1F1D are nineteen (19) transistors. Between the transistors are various other components. There are different colors of resistors, diodes and capacitors.

Below is a row of ribbon resistors, flanked by two (2) ribbon resistors and two ribbon capacitors. Listed along the top edge of the DS380ONFEXIBIA are the letters A to, and on the left edge next to the connector port are the numbers 10 to 80 times 10. There are more ribbon resistors, solid red resistors, and ribbon capacitors on the right side of the card.
