产品描述

该DS3800NFLA1C1C由通用电气（GE）制造。这是一个子板， 或如果需要，可以连接到更大的电路板的电路板.这为更大的电路板提供了更多的元件.该DS3800NFLA1C1C被创建为Speedtronic Mark IV涡轮机控制系列的组件。

DS3800NFLA1C1C是一个非常小的电路板.在左半部分，它包含八（8）个由初始CR标识的黑色和棕色二极管。这些二极管旁边是四 （4） 个跳线引脚。另外七 （7） 个跳线引脚位于DS3800NFLA1C1C的另一端。使用跳线，可以连接两个相邻的跳线引脚。这会改变电路板的功能.电路板上的特色是一个由初始 C 标识的 12 伏橙色大电容器。该设备旁边是一个矩形银色继电器或接触器，由首字母 K 标识。此继电器标有编号 8301。

在卡的中心附近可以看到三 （3） 个圆形银色晶体管。这些晶体管由字母Q标识。DS3800NFLA1C1C上可以找到一些小电阻器。这些电阻器覆盖在彩色带中，可用于找出每个器件的电阻容量。电阻器由字母R标识，在这些小电阻器附近是一个非常小的二极管，颜色为灰色和黑色。该二极管可以通过首字母CR来识别，并命名为CR11。

DS3800NFLA1C1C 这是一个子板

Product description

The DS3800NFLA1C1C was manufactured by General Electric (GE). This is a child board, or a board that can be attached to a larger board if needed. This provides more components for larger boards. The DS3800NFLA1C1C was created as a component of the Speedtronic Mark IV turbine control family.

The DS3800NFLA1C1C is a very small circuit board. In the left half, it contains eight (8) black and brown diodes identified by the initial CR. Next to these diodes are four (4) jumper pins. The other seven (7) jumper pins are located at the other end of DS3800NFLA1C1C. With a jumper, you can connect two adjacent jumper pins. This changes the functionality of the board. Featured on the board is a large 12-volt orange capacitor identified by the initial C. Next to the device is a rectangular silver relay or contactor, identified by the initial K. This relay is marked with number 8301.

Three (3) round silver transistors can be seen near the center of the card. These transistors are identified by the letter Q. Some small resistors can be found on DS3800NFLA1C1C. These resistors are covered in a color strip and can be used to find out the resistance capacity of each device. The resistors are identified by the letter R. Near these small resistors is a very small diode, colored gray and black. The diode can be identified by the initial letter CR and is named CR11.
