产品描述

531X124MSDAGG1是通用电气生产的抑制器电路板。531X124MSDAGG1 是一款小型电路板，没有太多内容。531X124MSDAGG1 具有三个大的深红色圆形聚酯电容器和两个大的黄色聚丙烯电容器。这些电容器用于产生电场，然后用于存储额外的能量供电路板使用.531X124MSDAGG1 有四个金属插脚散布在电路板周围。531X124MSDAGG1 具有四个带条的大型浅蓝色电阻器。电阻器条与彩色代码一起使用，以确定每个电阻器可以限制的能量量。每个彩色条带对应一个数字，可用于公式中确定电阻。

531X124MSDAGG1 具有两个大的银色电阻器和一个黑色长电阻器。

531X124MSDAGG1有一个大变压器。变压器是一种静电装置，通过电磁感应在两个或多个电路之间传输电能。变压器一个线圈中的变化电流产生不同的磁场，进而在第二个线圈中感应出不同的电动势或“电压”。变压器有三根黑线。两根电线很粗，一根很细。细线固定在电路板上， 而另外两根较粗的电线没有.两根粗线确实有圆形孔眼，末端有一个红色连接器。电路板上有八个孔.四个孔有金属边框，其余孔没有边框。

531X124MSDAGG1 是GE抑制器电路板

Product description

The 531X124MSDAGG1 is a suppressor circuit board manufactured by General Electric. The 531X124MSDAGG1 is a small board that doesn't have much content. The 531X124MSDAGG1 has three large dark red round polyester capacitors and two large yellow polypropylene capacitors. These capacitors are used to generate an electric field, which is then used to store additional energy for use on the circuit board. The 531X124MSDAGG1 has four metal pins scattered around the circuit board. The 531X124MSDAGG1 has a large light blue resistor with four strips. Resistor strips are used with color codes to determine the amount of energy each resistor can limit. Each color strip corresponds to a number that can be used to determine the resistance in the formula.

The 531X124MSDAGG1 has two large silver resistors and one long black resistor.

The 531X124MSDAGG1 has a large transformer. A transformer is an electrostatic device that transmits electrical energy between two or more circuits by electromagnetic induction. The changing current in one coil of the transformer generates a different magnetic field, which in turn induces a different electromotive force or "voltage" in the second coil. The transformer has three black wires. Two wires are thick and one is thin. The thin wires are fixed to the board, while the other two thicker wires are not. The two thick wires do have round holes with a red connector at the end. There are eight holes in the circuit board. Four holes have metal borders and the remaining holes have no border.
