产品描述

GE电源连接板531X122PCNAMG1是多个原始设备电源连接板的更新部件。 要配置主板以与您的驱动器兼容，GE 电源连接板 531X122PCNAMG1 上有跳线，允许您将电路板配置为与要更换的板相同。使用主板附带的信息了解如何为驱动器设置跳线。此外，可能还有其他必须设置的跳线。仔细检查有缺陷的电路板，并将所有跳线设置在新板上的相同位置。使用跳线标识符将有缺陷的电路板上的跳线与新板上的相同跳线相匹配，因为您可能会发现跳线位于新板上的不同位置。

电缆也可能连接在旧板上。在用连接器编号和任何其他有用信息标记它们之前，不要断开它们的连接。这样，您就可以轻松快速地将它们连接到新板上。

断开电缆与有缺陷的电路板的连接时必须小心，因为电缆很脆弱，如果处理不当可能会断裂。带状电缆由多根细线组成，可以很容易地从连接器上断开。仅从连接器上抓住带状电缆以断开连接。用一只手稳定电路板，另一只手抓住带状电缆。然后，从主板上拔出连接器。

531X122PCNAMG1是多个原始设备电源连接板的更新部件

Product description

The GE power connector 531X122PCNAMG1 is an updated part of multiple original device power connectors. To configure the motherboard to be compatible with your drive, there are jumpers on the GE power connector 531X122PCNAMG1 that allow you to configure the board to be the same as the board you want to replace. Use the information that came with the motherboard to learn how to set up jumpers for your drive. In addition, there may be other jumpers that must be set. Carefully inspect the defective circuit board and set all jumpers in the same position on the new board. Use the jumper identifier to match the jumper on the defective board to the same jumper on the new board, as you may find that the jumper is located in a different location on the new board.

Cables may also be attached to old boards. Do not disconnect them before labeling them with connector numbers and any other useful information. This way, you can easily and quickly connect them to the new board.

Care must be taken when disconnecting cables from defective circuit boards, as cables are fragile and can break if not handled properly. The ribbon cable consists of multiple thin wires that can be easily disconnected from the connector. Grab the ribbon cable from the connector only to disconnect the connection. Stabilize the board with one hand and hold the ribbon cable with the other. Then, remove the connector from the motherboard.
