产品描述

GE电源连接板531X122PCNALG1是多个原始设备电源连接板的更新部件。 要使 GE 电源连接板 531X122PCNALG1 与它可以替换的多个原始板兼容，必须设置两个跳线。跳线为 JP1 和 JP2，它们配置直流电枢电压范围。要将 G1 电压设置为 500 VDC，将 G2 设置为 700 VDC，请将跳线引脚未覆盖，并保存跳线以备将来使用。要将 G1 电压配置为 240 VDC，G2 电压配置为 550 VDC，请在引脚 P3 和 P4 上插入一个跳线。对于 JP2，将跳线插入引脚 P5 和 P6 上。

要更换现有主板，首先必须断开驱动器的所有电源。您可能需要与熟悉安装的人员协商，以确保所有电源都已断开。如果不断开所有电源，则存在触电、电灼伤或设备损坏的严重风险。

在开始处理驱动器和电路板之前，请确保您有可用的接地带，以保护电路板免受静电积聚的影响。表带的一端夹在工作台上未上漆的金属表面上。另一端缠绕在你的手臂上。通过这种方式，任何静电都会进入接地的工作台或其他金属表面。

531X122PCNALG1 是多块原设备电源连接板

Product description

The GE Power connector 531X122PCNALG1 is an updated part of multiple original device power connectors. To make the GE power connector 531X122PCNALG1 compatible with the multiple original boards it can replace, two jumpers must be set up. The jumpers are JP1 and JP2, which are configured with a DC armature voltage range. To set the G1 voltage to 500 VDC and G2 to 700 VDC, leave the jumper pins uncovered and save the jumper for future use. To configure G1 voltage to 240 VDC and G2 voltage to 550 VDC, insert a jumper on pins P3 and P4. For JP2, insert the jumper into pins P5 and P6.

To replace an existing motherboard, you must first disconnect all power to the drive. You may need to consult with someone familiar with the installation to ensure that all power is disconnected. If all power is turned on constantly, there is a serious risk of electric shock, electrical burn, or equipment damage.

Before you start working with the driver and board, make sure you have available ground strips to protect the board from static buildup. One end of the strap is clipped to an unpainted metal surface on the workbench. The other end wraps around your arm. In this way, any static electricity will enter a grounded workbench or other metal surface.以上翻译结果来自有道神经网络翻译（YNMT）· 通用场景
