产品描述

GE电源连接板531X121PCRAHG3是多个原始设备电源连接板的更新部件。 531X121PCRAHG3 板可配置为提供多个电源连接板所需的电压。使用开发板上的两个跳线将其配置为与原始主板兼容。该板包含设置两个跳线所需的信息。

确定跳线设置后，从装运板的纸箱中取出电路板。仅握住电路板的侧面，以防止因意外弯曲引脚、损坏连接器或损坏其他组件而损坏组件。取下保护袋并将袋子压平在干净干燥的表面上，例如工作台。用手指或一把钳子移动跳线以覆盖正确的针脚。不要放下跳线或强迫跳线越过大头针。您可能会弯曲或折断大头针。此外，如果驱动器中丢失了跳线，则必须将其取回以避免损坏驱动器组件。

打开固定旧板的卡舌，并仔细注意电缆的连接位置。将电缆连接到新主板上的相同连接器，然后将电路板安装在驱动器中。通过按下将电路板锁定到位的卡舌来固定电路板。

GE电源连接板531X121PCRAHG3

Product description

The GE power connector 531X121PCRAHG3 is an updated part of multiple original device power connectors. The 531X121PCRAHG3 board can be configured to provide the voltage required for multiple power supply boards. Configure it to be compatible with the original motherboard using two jumpers on the development board. The board contains the information needed to set up the two jumpers.

After determining the jumper Settings, remove the circuit board from the carton of the shipping board. Hold only the sides of the board to prevent damage to the components from accidentally bending pins, damaging connectors, or damaging other components. Remove the protective bag and flatten the bag on a clean, dry surface, such as a workbench. Move the jumper with your finger or a pair of pliers to cover the correct stitch. Do not drop the jumper or force the jumper over the pin. You may bend or break the pin. Also, if a jumper is missing from the drive, it must be retrieved to avoid damaging the drive components.

Open the latch that holds the old plate in place and pay careful attention to where the cable is connected. Connect the cable to the same connector on the new motherboard, then mount the board in the driver. The board is secured by pressing down on the latch that locks the board into place.
