产品描述

531X113PSFASG1是通用电气制造的电源接口板。它用于GE的各种通用驱动系统，而不是作为某个特定系统的组件创建的。请查看系统的用户指南以了解兼容性。

531X113PSFASG1 是一款组件丰富的电路板。电路板的右上象限大量由大型电容器元件组成。这些往往是铝电解电容器。该象限还包括三个散热器和四个电感线圈。该板有三个保险丝，两个在这里，一个在右下象限的正下方。该象限主要由六个接头连接器（一个两针连接器、一个四针连接器、两个六针连接器和两个 9 针连接器）、三个继电器和几个电容器组成。该象限还包括电路板的垂直引脚电缆连接器之一。531X113PSFASG1 共有六个电缆连接器。所有连接器均为公头垂直引脚连接器。

531X113PSFASG1 的其他组件包括集成电路、碳复合材料和金属膜制成的电阻器、电阻器网络阵列、六个电位计、一个总共有六个拨动开关的开关组件、跳线开关、TP 测试点和二极管，包括三个 LED（发光二极管）指示灯。大多数组件都标有参考标志，以便快速识别。如果需要有关组件或主板的功能、使用或操作（包括维护和安装）的更多信息，请参阅引用此主板编号的制造商出版物。531x系列的技术支持由通用电气提供。

通用电气531X113PSFAPG1dcs卡件模块电源连接卡

Product description

The 531X113PSFASG1 is a power interface board manufactured by General Electric. It is used in GE's various general-purpose drive systems, rather than being created as a component of a particular system. Check your system's user guide for compatibility.

The 531X113PSFASG1 is a component-rich circuit board. The upper right quadrant of the board is largely composed of large capacitor components. These are often aluminum electrolytic capacitors. The quadrant also includes three radiators and four inductors. The board has three fuses, two here and one directly below in the lower right quadrant. The quadrant consists mainly of six splice connectors (one two-pin connector, one four-pin connector, two six-pin connectors, and two nine-pin connectors), three relays, and several capacitors. The quadrant also includes one of the vertical pin cable connectors for the board. The 531X113PSFASG1 has six cable connectors. All connectors are male vertical pin connectors.

Other components of the 531X113PSFASG1 include integrated circuits, resistors made of carbon composite and metal film, resistor network arrays, six potentiometers, a switch assembly with a total of six toggled switches, jumper switches, TP test points and diodes, including three LED (light-emitting diode) indicators. Most components are marked with reference marks for quick identification. If you need more information about the function, use, or operation of a component or motherboard, including maintenance and installation, please refer to the manufacturer's publication that references this motherboard number. Technical support for the 531x series is provided by General Electric.
