产品描述

531X111PSHSWG2卡是通用电气制造的电机场控制和电源板。作为GE的531X系列替换板的成员，该卡可以安装到GE系列的驱动器阵列中。安装此卡可提供正常运行的驱动功能所需的电源。由于该板是作为 G2 版本开发的，因此安装在外部激励器中时功能最佳。

安装此电源板可为驱动器提供三个可接受的电压源。531X111PSHSWG2 可产生额定电压为 5 VDC、15 VDC 和 24 VDC。驱动器的电机励磁电路也从电路板的集成脉冲变压器接收电源。可通过卡执行许多控制选项和系统校准。三个板载继电器允许用户执行系统控制选项。这些可以在卡上标识为 K1 （运行）、K2 （最大） 和 K3 （故障）。该卡还包含三个电位计和五个跳线。电路和电流反馈调整由电位计执行，而电流和反馈信号的调整则由跳线执行。

通用电气提供了许多安装参数，在开始设备安装之前应检查这些参数。 为确保设备不会遭受任何可预防的损坏，该卡只能由合格的人员处理。请务必查看设备的手册和数据表，以获取全面的安装和接线指南。该设备的制造商通用电气最初为该卡提供了技术支持。

531X111PSHSWG2卡是通用电气制造的电机场控制和电源板

Product description

The 531X111PSHSWG2 card is an electric field control and power board manufactured by General Electric. As a member of the GE 531X series replacement board, the card can be installed into the GE series drive array. Installing this card provides the power required for proper operation of the driver function. Since the board was developed as a G2 version, it functions best when installed in an external driver.

Installing this power supply board provides the driver with three acceptable voltage sources. The 531X111PSHSWG2 can produce rated voltages of 5 VDC, 15 VDC and 24 VDC. The driver's motor excitation circuit also receives power from an integrated pulse transformer on the board. Many control options and system calibrations can be performed via the card. Three onboard relays allow the user to perform system control options. These can be identified on the card as K1 (running), K2 (maximum), and K3 (failure). The card also contains three potentiometers and five jumpers. Circuit and current feedback adjustment is performed by the potentiometer, while current and feedback signal adjustment is performed by the jumper.

Ge provides a number of installation parameters that should be checked before starting equipment installation. To ensure that the equipment does not suffer any preventable damage, the card should only be handled by qualified personnel. Be sure to check your device's manual and data sheet for comprehensive installation and wiring guidelines. General Electric, the manufacturer of the device, initially provided technical support for the card.
