产品描述

通用电气的 531X111PSHAWG3 卡最初开发用作电源和电机场控制板。该卡是作为GE 531X替换卡系列的替换板开发的。GE 系列中的较旧驱动器可以将此卡安装在设备的机柜中。安装卡可为主机驱动器提供正常运行所需的电源。作为 G3 板版本开发，该卡 f用于未安装在板上的交流线路的 MOV。MOV 安装在外部而不是电路板上。

安装后，531X111PSHAWG3 板为驱动器提供三个电源。用户可以从 5 VDC、15 VDC 和 24 VDC 中选择所需的电压。此外，该卡还提供一个集成的脉冲变压器，为已安装驱动器的电机励磁电路供电。该板还具有许多附加功能。在板载上，该卡包括三个继电器点。这些继电器允许用户在电路板上执行系统控制功能。卡上还具有三个电位计和五个跳线。 电位计允许对电流和电路反馈进行调整，而跳线允许校准电流和反馈信号。

在开始设备安装之前，应检查任何制造商提供的安装参数。仅允许经过培训的驱动器板用户安装此卡。 531X111PSHAWG3 电源板的综合接线指南可在系列手册和器件数据表中找到。设备制造商通用电气最初为该卡提供了技术支持。

GE 531X111PSHAWG3 电源卡 531 x系列 电机磁场控制 5/15/24直流

Product description

The General Electric 531X111PSHAWG3 card was originally developed for use as a power supply and electrical field control board. The card was developed as a replacement board for the GE 531X replacement card family. Older drives in the GE series can install this card in the cabinet of the device. The installation card provides power to the host drive for proper operation. Developed as a G3 board version, the card f is used for MOV on AC lines that are not installed on the board. MOV is installed externally instead of on the board.

Once installed, the 531X111PSHAWG3 board provides three power supplies to the drive. Users can choose the desired voltage from 5 VDC, 15 VDC, and 24 VDC. In addition, the card offers an integrated pulse transformer that powers the motor excitation circuit with an installed driver. The board also has many additional features. On board, the card includes three relay points. These relays allow the user to perform system control functions on the circuit board. The card also has three potentiometers and five jumpers. The potentiometer allows the current and circuit feedback to be adjusted, while the jumper allows the current and feedback signals to be calibrated.

Before starting equipment installation, check any installation parameters provided by the manufacturer. Only trained drive board users are allowed to install this card. Comprehensive wiring guidelines for the 531X111PSHAWG3 power supply board can be found in the series manual and device data sheet. Device manufacturer General Electric initially provided technical support for the card.
