产品描述

通用电气将 531X111PSHASG1 卡设计为电机磁场控制和电源板。它专为 GE 驱动器的 531X 系列更换板而设计。该系列中的大多数驱动器都可以在其机柜中接受此卡。安装后，该板提供驱动器运行所需的电源。电机励磁电路也从卡接收电源。

由于此卡为驱动器供电，因此它对整体操作具有重要作用。531X111PSHASG1可以为驱动器提供三种不同的额定电压。创建的电源包括 5 VDC、15 VDC 和 24 VDC。电路板的集成脉冲变压器也为电机励磁电路提供电源。板上的继电器也可用，包括运行 （K1）、最大 （K2） 和故障 （K3）。电流和电路反馈可以使用卡上的三个电位计进行校准和调整。用户还可以配置五个跳线来调整和修复反馈和电流信号。

应遵循制造商提供的有关安装的参数。遵循这些准则后，电路板损坏或缺陷的风险就会降低。驱动板只能由经过培训的合格人员安装，以处理这些卡。 有关 531X111PSHASG1 接线指南，请参阅器件的相应数据表和手册。 该板的制造商通用电气最初为该卡提供技术支持。

531X111PSHASG1 卡设计为电机磁场控制和电源板

Product description

Ge designed the 531X111PSHASG1 card as a motor magnetic field control and power supply board. It is designed for the 531X series replacement board of GE drives. Most drives in this series can accept this card in their cabinets. Once installed, the board provides the power needed for the drive to operate. The motor excitation circuit also receives power from the card.

Since this card powers the drive, it plays an important role in the overall operation. The 531X111PSHASG1 can provide three different voltage ratings for the driver. The power supply can be 5 VDC, 15 VDC, or 24 VDC. The circuit board's integrated pulse transformer also provides power to the motor excitation circuit. On-board relays are also available, including run (K1), Max (K2), and fault (K3). Current and circuit feedback can be calibrated and adjusted using the three potentiometers on the card. Users can also configure five jumpers to adjust and repair feedback and current signals.

The installation parameters provided by the manufacturer should be followed. By following these guidelines, the risk of damage or defects to the board is reduced. The driver boards should only be installed by qualified personnel trained to handle these cards. For wiring guidelines for the 531X111PSHASG1, refer to the appropriate data sheet and manual for the device. General Electric, the board's manufacturer, initially provided technical support for the card.
