产品描述

通用电气531X111PSHARG2卡是一种电机场控制和电源板。 开发时，此卡是为 531X 系列替换板制造的。GE制造的任何数量的驱动器和励磁器都可以在其机柜中安装此卡。此电源板提供驱动器运行所需的电源。它还包含为电路板的电机场电路供电的适当设备.作为该板的 G2 修订版，该卡专为与外部激励器配合使用而开发。

531X111PSHARG2 为驱动器提供正常运行所需的必要电源。额定电压为 5 VDC、15 VDC 和 24 VDC 的电源均可由该卡产生。驱动器上的电机场电路由卡的集成脉冲变压器供电。该卡包含三个继电器：运行 （K1）、最大 （K2） 和故障 （K3），以提供系统控制选项。电路板上还集成了三个电位计。P1（场标度）、P2（CFB ZERO）和P3（CFB ADJUST）都允许用户校准或调整电路或电流反馈。五个可配置的跳线允许用户选择和调整反馈和电流信号。

安装卡时，请务必遵循所有提供的安装参数。 应满足制造商提供的任何准则，以保护设备的完整性。仅允许具有处理驱动板资格的训练有素的人员安装此卡。531X111PSHARG2 板的完整接线和安装指南可在器件手册和数据表中找到。该电源板的技术支持最初由设备制造商通用电气提供。

GE通用电气 531X111PSHARG2控制器模块

Product description

The General Electric 531X111PSHARG2 card is an electric field control and power board. At the time of development, the card was manufactured for the 531X series replacement board. Any number of drivers and exciters manufactured by GE can have the card installed in their cabinets. This power strip provides the power needed to run the drive. It also contains the appropriate equipment to power the electrical field circuit of the board. As a G2 revision of the board, the card was developed specifically for use with external exciters.

The 531X111PSHARG2 provides the necessary power to the drive for proper operation. Power supplies rated at 5 VDC, 15 VDC, and 24 VDC can be generated from the card. The field circuit on the driver is powered by the card's integrated pulse transformer. The card contains three relays: Run (K1), Max (K2), and Fault (K3) to provide system control options. Three potentiometers are also integrated on the board. P1 (field scale), P2 (CFB ZERO), and P3 (CFB ADJUST) all allow users to calibrate or adjust circuits or current feedback. Five configurable jumpers allow users to select and adjust feedback and current signals.

When installing the card, be sure to follow all provided installation parameters. Any guidelines provided by the manufacturer should be met to protect the integrity of the equipment. Only trained personnel qualified to handle driver boards are allowed to install this card. Complete wiring and installation guidelines for the 531X111PSHARG2 board can be found in the device manual and data sheet. Technical support for the power board was initially provided by device manufacturer General Electric.
