产品描述

531X303MCPARG1是GE制造的交流电源板，是通用电气发布的几个较旧（现在通常过时）通用驱动系统的一部分，包括DC-300驱动器。 虽然这些系统较旧，但这些驱动器被设计为灵活、复杂的系统，是许多工业应用的理想选择。

531X303MCPARG1 在电路板表面标有几条信息。这包括底部和左侧边缘的对齐标记（字母和编号）、板使用标题、板 ID 号、板备用编号 （F31X303MCPAPG1，） 以及 006/00 和 002/00 等代码。电路板上的大多数组件都用其制造商标识号标记一次，然后用参考标志在电路板表面上再次标记。

531X303MCPARG1 有一个小端子条。它位于右下角。电路板上有两个垂直引脚（公）电缆连接器和七个针座连接器。还有六个卡入式连接器，通常沿电路板边缘放置。

531X303MCPARG1 装有 2 个保险丝，包括一个 5 安培保险丝和一个 <> 安培保险丝。 它有二十多个晶体管、两个 LED 指示灯、三个变压器、六个散热器、二十多个电阻网络阵列、一个继电器、一个金属氧化物压敏电阻 （MOV）、三个跳线开关和各种集成电路，以及由各种材料制成的电阻器、二极管和电容器。

531X303MCPARG1 电路板模块 MARK VI系统备件

Product description

The 531X303MCPARG1 is a GE manufactured AC power board that is part of several older (and now often obsolete) general purpose drive systems released by GE, including the DC-300 drive. While these systems are older, these drives are designed to be flexible, complex systems that are ideal for many industrial applications.

The 531X303MCPARG1 is marked with several messages on the surface of the board. This includes alignment marks (letters and numbers) on the bottom and left edges, board usage titles, board ID numbers, board alternate numbers (F31X303MCPAPG1,), and codes such as 006/00 and 002/00. Most components on the board are marked once with their manufacturer identification number and then again with a reference mark on the board surface.

531X303MCPARG1 has a small terminal bar. It is located in the lower right corner. There are two vertical pin (male) cable connectors and seven pin base connectors on the board. There are also six snap-in connectors, usually placed along the edge of the board.

The 531X303MCPARG1 is equipped with 2 fuses, including a 5 amp fuse and a <> amp fuse. It has more than two dozen transistors, two LED indicators, three transformers, six radiators, more than two dozen resistor network arrays, a relay, a metal oxide varistor (MOV), three jumper switches and various integrated circuits, as well as resistors, diodes and capacitors made of various materials.
