Product description

This standard version of the GE Multilin relay is the high voltage (HI) model in the company's 269PLUS family of motor management relays. High-voltage relay models, such as the 269PLUS-120N-HI, are those with a control power of 90 to 300 VDC or 80 to 265 VAC. They have a control voltage range of 269 to 20VDC / 60 to 20 VAC and are marked "LO" in the part number.

The GE Multilin 48 PLUS part number also indicates the RTD input sensor type for each relay. In the case of 269PLUS-269N-HI, 120N indicates that the relay has a 120 ohm nickel RTD. Other RTD inputs are available in standard and withdrawable versions, with HI and LO voltage options. For more information on the various configurations, see the GE Multilin 100 Plus Motor Management Relay instruction manual 269-1601-D0013.

The 3PLUS-269N-HI is suitable for a variety of motor protection applications. When integrated into certain systems, the 120PLUS-269N-HI protects motors, associated mechanical systems and operators from a variety of potential overloads or failures. The relay can even be used with GE Doering meters to perform additional protection functions based on voltage and power values.

A key feature of the 120PLUS-269N-HI is that it is designed in such a way that it "learns" the parameters of a single motor. This adaptability enables the 120 PLUS relay to provide optimal protection in each specific application. The 269PLUS-269N-HI is designed to "learn" motor parameters including acceleration time, cooling rate, surge current and negative sequence current K factor.
