SR469-P5-HI-A20-H GE Multilin 电机管理继电器

SR469-P5-HI-A20-H  GE Multilin 电机管理继电器

SR469-P5-HI-A20-H  GE Multilin 电机管理继电器

469-P5-HI-A20-H零件号指的是多线469马达管理继电器部件。这是Multilin电机保护系统的一部分，为中压电机提供经济高效的控制、通信和简单的配置选择。Multilin 469继电器具有最短的更换时间，提供完整的资产监控，可现场升级，通常可减少故障排除和维护的成本和时间。

469-P5-HI-A20-H的前面板包括三行状态指示器。这些指示器的一行专用于469继电器，另一行用于电机状态，第三行用于输出状态。这些指示器上方有一个40字符的大显示屏，可用于诊断和默认信息。面板还包括数字键盘、数值上下键、控制键和编程键(菜单、退出、输入、复位、菜单上下键)。面板底部包括一个抽出式手柄，可以密封以防止未经授权的移动。

469-P5-HI-A20-H包括RS232连接端口接口。这提供了9600到19200波特率的连接。该装置是一个额定电压为90-300伏直流电、70-265伏交流电、频率为48-62赫兹的5安培相CT次级线圈。该装置有四个4-20 mA模拟输出。469-P5-HI-A20-H可以在恶劣的环境中使用。

SR469-P5-HI-A20-H  GE Multilin 电机管理继电器

The 469-P5-HI-A20-H part number refers to the multi-wire 469 motor management relay component. This is part of the Multilin motor protection system, which provides cost-effective control, communication and simple configuration options for medium voltage motors. The Multilin 469 relay has the shortest replacement time, provides complete asset monitoring, can be upgraded in the field, and generally reduces the cost and time of troubleshooting and maintenance.

The front panel of the 469-P5-HI-A20-H includes three rows of status indicators. One line of these indicators is dedicated to the 469 relay, another line is for the motor status, and a third line is for the output status. Above these indicators is a large 40-character display that can be used for diagnostics and default information. The panel also includes a numeric keypad, numeric up and down keys, control keys, and programming keys (menu, exit, input, reset, menu up and down keys). The bottom of the panel includes a pull-out handle that can be sealed to prevent unauthorized movement.

469-P5-HI-A20-H Includes RS232 connection port interface. This provides a connection of 9600 to 19200 baud rates. The device is a 5 amp phase CT secondary coil rated at 90-300 volts DC, 70-265 volts AC, and 48 to 62 Hz. The unit has four 4-20 mA analog outputs. 469-P5-HI-A20-H can be used in harsh environments.
