DS215KLDCG1AZZ03A 触点输入组隔离端子板

DS215KLDCG1AZZ03A 触点输入组隔离端子板

DS215KLDCG1AZZ03A 触点输入组隔离端子板

产品介绍

型号名称：DS215KLDCG1AZZ03A

自动设置菜单 为垂直系统、水平系统和触发系统单键自动设置所有通道，支持撤销自动设置操作

方波 单周期, 多周期, 上升沿或下降沿

正弦波 单周期, 多周期, FFT频谱

视频(NTSC, PAL, SECAM) 场：所有场, 奇数场或偶数场；

行：所有行或可以选择行数

自动量程 在点到点移动探头或在信号表现出较大变化时，自动调节垂直和 /或水平示波器设置

显示特点

彩色型号 1/4 VGA无源彩色LCD，黑色背景上各种颜色，并且可以调节多级对比度

单色型号 1/4 VGA背灯无源LDC，并且可以调节多级对比度，可以从前面板中反选视频

内插 Sin(x)/x

显示器类型 点, 矢量

余辉 Off, 1 s, 2 s, 5 s, 无穷大

格式 YT和XY

环境和安全

温度 工作温度: 0℃到+50℃。

非工作温度: - 40℃到+71℃

湿度 工作湿度和非工作湿度: 等于或低于+40℃时80%相对湿度。

工作湿度和非工作湿度: +50℃时高达 45%相对湿度

高度 工作高度和非工作高度: 3,000米。
