产品描述

GE RST 溢出板DS200TCQCG1BKG装有 24 个跳线和 3 个 40 针连接器。它还具有 3 个 34 针连接器和 1 个 16 针连接器。分配给 16 针连接器的 ID 是 JC。分配给 40 针连接器的 ID 是 JFF、JE 和 6PL。

GE RST溢流板DS200TCQCG1BKG还装有散热片。在安装和卸下主板之前，请考虑以下有关散热器的信息。散热器从电路板突出，因此如果主板夹在一起，则电路板不能放置在驱动器内部其他电路板的 3 英寸范围内。这是为了留出散热器的间隙，并为散热器提供散发额外热量所需的气流。另一个注意事项是，当您将主板排列在驱动器中时，散热器可能会损坏其他主板和组件。您可能会不小心划伤另一块板或从另一块板上敲出精致的组件。另外，请注意避免将电路板刮到其他组件上并敲掉散热器。

分配给跳线的 ID 以 BJ 为前缀，后跟一个数字。例如，为跳线分配 ID BJ1、BJ5 和 BJ24。每个跳线的说明包含在工厂随附的电路板说明中。跳线由跳线 ID 引用。当GE RST溢出板DS200TCQCG1BKG最初安装在驱动器中时，安装程序会移动跳线以配置板以满足现场的处理需求。

GE RST 溢出板 DS200TCQCG1BKG 驱动器控制端子板

Product description

The GE RST overflow board DS200TCQCG1BKG is equipped with 24 jumpers and 3 40-pin connectors. It also features three 34-pin connectors and one 16-pin connector. The ID assigned to the 16-pin connector is JC. The ids assigned to 40-pin connectors are JFF, JE, and 6PL.

The GE RST overflow plate DS200TCQCG1BKG is also equipped with a heat sink. Before installing and removing the motherboard, consider the following information about the heat sink. The heat sink protrudes from the board, so if the main board is clamped together, the board cannot be placed within 3 inches of other boards inside the drive. This is to leave a gap in the radiator and provide the air flow needed for the radiator to dissipate additional heat. Another note is that when you line up the motherboard in the drive, the radiator can damage other motherboards and components. You may accidentally scratch another board or knock delicate components out of another board. Also, be careful to avoid scraping the circuit board onto other components and knocking off the radiator.

The ID assigned to the jumper is prefixed with BJ followed by a number. For example, assign ids BJ1, BJ5, and BJ24 to jumpers. Instructions for each jumper are included in the circuit board instructions that come with the factory. The jumper is referenced by the jumper ID. When the GE RST overflow board DS200TCQCG1BKG is initially installed in the drive, the installer moves the jumper to configure the board to meet the processing requirements in the field.
