产品描述

DS200SIOBH1ACA Mark V印刷电路板用作ARCNET连接PCB。 该装置最初设计为LM系列的一部分，LM系列是通用电气Mark V Speedtronic系列的一部分。该系列多年来一直用于工业涡轮机系统的控制和管理。

DS200SIOBH1ACA允许外部放置的模块或 I/O 内核与 <R> 控制引擎连接。该板用于将这些单元与ARCNET通信协议连接。该主板与包含 486DX 处理器/CPU 的 UCPB 主板和包含 196 处理器芯片的 UCIA 主板结合使用。该芯片用于转换压力传感器信号。

该DS200SIOBH1ACAC包括多个 BNC 连接器。 这些用于将文件下载到控制引擎，通常以 100 Hz 或 10 ms 的速率发生。该板通常缩写为 AAHA，还包括其他连接器。AAHA 包括一个 APL ArcNet 通信链路和一个 2PL 连接器，用于从 <R> 内核中的 TCPS 板分配电源。板上的其他连接器（如 EPL 和 EBNC）通常不使用。该板标有通用电气徽标。它还包括其ID标记和代码，可帮助用户进行定位和布线。电路板的大多数组件都标有参考名称。该板的两个继电器包括直接位于其顶部的继电器图，安装或故障排除工程师或技术人员可以清楚地看到。

DS200SIOBH1ACA燃机卡件控制器模块备件

Product description

The DS200SIOBH1ACA Mark V printed circuit board is used as an ARCNET connection PCB. The unit was originally designed as part of the LM series, part of the General Electric Mark V Speedtronic series. The series has been used for many years for the control and management of industrial turbine systems.

The DS200SIOBH1ACA allows externally placed modules or I/O cores to connect to the <R> control engine. The board is used to connect these units to the ARCNET communication protocol. This motherboard is used in combination with the UCPB motherboard containing the 486DX processor /CPU and the UCIA motherboard containing the 196-processor chip. The chip is used to convert pressure sensor signals.

The DS200SIOBH1ACAC includes multiple BNC connectors. These are used to download files to the control engine and typically occur at a rate of 100 Hz or 10 ms. The board, often abbreviated as AAHA, also includes other connectors. AAHA includes an APL ArcNet communication link and a 2PL connector for distributing power from the TCPS board in the <R> kernel. Other connectors on the board, such as EPL and EBNC, are usually not used. The board is marked with the GE logo. It also includes its ID tag and code to help the user locate and route. Most components of the board are labeled with reference names. The board's two relays include a relay diagram located directly on top of it that can be clearly seen by the installation or troubleshooting engineer or technician.
