IC2OOBEM003模块是GE Fanuc设计的Versamax主模块。它可以很容易地在V1 PROFINET网络上发送/接收数据。它支持可变数据速率。使用该模块可以处理总共3584字节的输入数据和3584字节的输出数据。

该模块具有同步和冻结模式。该网络接口模块的数据速率范围在9.6 k波特和12M波特之间。IC2OOBEM003模块使用两端终止的线性总线网络拓扑。它使用屏蔽双绞线电缆进行数据和信息传输。网络模块使用9针D-sub连接器进行连接。它的尺寸很小，紧凑的尺寸为4.3英寸宽，2.63英寸高，1.956英寸深。

Versamax IC200BEMO03模块是一个智能模块，带有从状态数组表、从诊断地址和其他功能。它从5伏输出消耗总共450毫安的电流。

IC200BEM003模块可通过主机控制器和使用Windows操作系统的软件实用程序进行配置。模块的前部有LED指示灯，当有通信活动时会亮起。

IC2OOBEM003模块可以支持多达125个从设备，并且可以通过软件进行配置。网络至机架接地隔离额定值为250伏交流电，PROFIBUS网络至背板额定值为1500伏交流电，持续1分钟。该模块已通过UL危险区域安装标准认证。

GE通用电气IC200BEM003 控制模块 通讯系统备件

The IC2OOBEM003 module is the main module of the Versamax designed by GE Fanuc. It can easily send/receive data on V1 PROFINET network. It supports variable data rates. A total of 3584 bytes of input data and 3584 bytes of output data can be processed using this module.

The module has sync and freeze modes. The data rate of the network interface module ranges from 9.6k baud to 12M baud. The IC2OOBEM003 module uses a linear bus network topology terminated at both ends. It uses shielded twisted pair cables for data and information transmission. The network module is connected using a 9-pin D-sub connector. It is small in size, with a compact size of 4.3 inches wide, 2.63 inches high, and 1.956 inches deep.

The Versamax IC200BEMO03 module is a smart module with slave state array table, slave diagnostic address and other functions. It consumes a total of 450 milliamps of current from 5 volts.

The IC200BEM003 module can be configured through the host controller and software utilities using the Windows operating system. The front of the module has an LED indicator that lights up when there is communication activity.

The IC2OOBEM003 module can support up to 125 slave devices and can be configured through software. The network to rack grounding isolation is rated at 250 volts AC and the PROFIBUS network to backplane is rated at 1500 volts AC for 1 minute. The module is certified to the UL Hazardous Area Installation standard.
