DS200SI0CG1AEA LS2100 系列静态起动器控制器

接口功能：作为驱动器控制电路和SCR电源桥之间的接口，DS200PCCAG1ACB能够实现两者之间的有效连接和数据传输。

电源分配与连接：该组件具有电源分配和连接功能，能够将直流电源分配到电力系统的各个组件和设备，如控制器、驱动器、保护装置等。

保护功能:D S200PCCAG1ACB可能还具备过流保护、过压保护、短路保护等功能，以确保电力系统的安全运行。

电枢电压范围:D S200PCCAG1ACB具有240-630伏的电枢电压范围，可满足不同应用场景的需求。

可配置性：该组件上设有四个可配置跳线（JP1、JP2、WP3和WP4），用户可以根据具体的应用需求进行配置，以调整电容器与电源桥和电压反馈通道的连接状态。

可再生性:D S200PCCAG1ACB是可再生的，意味着在损坏或故障时，可以通过维修或更换来恢复其功能。

DS200FCGDH1A 技术规格

电路板描述 栅极分配和状态电路板

电桥结构 SCR 双栈/散热器

功能缩写/简称 FCGD

光纤连接器数量 四个，三个蓝色，一个灰色

LED 数量 两个，OC FLT 和 IMOK (T) 激活

部件手册 GEI-100221

尺寸 6U VME（9.23 x 6.3 英寸）

DS200SI0CG1AEA LS2100 系列静态起动器控制器

Interface function: As the interface between the driver control circuit and the SCR power bridge, the DS200PCCAG1ACB can realize effective connection and data transmission between the two.

Power distribution and connection: This component has power distribution and connection functions to distribute DC power to various components and devices of the power system, such as controllers, drivers, protection devices, etc.

Protection function: DS200PCCAG1ACB may also have over current protection, over voltage protection, short circuit protection and other functions to ensure the safe operation of the power system.

Armature voltage range: The DS200PCCAG1ACB has an armature voltage range of 240-630 volts to meet the needs of different application scenarios.

Configurability: There are four configurable jumpers (JP1, JP2, WP3 and WP4) on the component, which can be configured by the user to adjust the connection state of the capacitor to the power bridge and voltage feedback channel according to the specific application requirements.

Renewable: The DS200PCCAG1ACB is renewable, meaning that in the event of damage or failure, its function can be restored by repair or replacement.

DS200FCGDH1A Technical specifications

Circuit board Describes the grid distribution and status circuit board

Bridge structure SCR double stack/radiator

Function abbreviation/short for FCGD

Number of fiber optic connectors four, three blue, one gray

The number of leds is two, OC FLT and IMOK (T) activation

Component manual GEI-100221

Size 6U VME (9.23 x 6.3 inches)
