DS200RTBAG3AHC 一款电力励磁板

DS200RTBAG3AHC是通用电气（GE）生产的一款电力励磁板，它通常安装在驱动柜中，具有10个继电器，这些继电器可以直接由导向继电器驱动或由用户远程驱动。该板具有52个端点，用于I/O（输入/输出）目的。例如，一系列的端子点用于继电器K20的C形触点，包括一个端子用于常开位置，一个端子用于公共位置，以及一个端子用于常闭位置。此外，该板还配备了两个插入式连接器，即CPH（正极电源连接器）和CPN（负极电源连接器），它们提供可插拔的电路控制电源。这些连接器连接到C1PL至C5PL和Y9PL至Y37PL可插拔电路，以便提供正负电源控制。

DS200RTBAG3AHC板在连接电源时含有高能量，因此在操作时需要格外小心，以避免安全风险。在进行任何维护或操作之前，必须遵循程序断开所有电源，以确保安全。

该产品广泛应用于工业自动化和控制系统，尤其是在需要精确控制和保护的燃气轮机或其他大型工业设备中。由于其高度的灵活性和可定制性，它在现代化工业领域，如电力、石油、矿井提升、港口、供热、燃气、供水、污水处理、冶金、造纸、纺织、化工、水利等都有应用。

输入电压：12-24 VDC

输出电压：10-20 VAC

输出电流：100 mA

操作温度范围：-40 至 +70 °C

尺寸：100 x 50 x 25 mm

重量：0.5 kg

端点：52个端点，用于I/O（输入/输出）目的

继电器：10个继电器，可以由导向继电器直接驱动或由用户远程驱动

连接器：两个插入式连接器 CPH（正极电源连接器）和 CPN（负极电源连接器），提供可插拔的电路控制电源

可插拔电路：C1PL 至 C5PL 和 Y9PL 至 Y37PL

安全注意事项：由于板上含有高能量，操作时需确保所有电源已断开，以避免安全风险

DS200RTBAG3AHC 一款电力励磁板

The DS200RTBAG3AHC is an electric excitation board produced by General Electric (GE) that is typically installed in a drive cabinet and has 10 relays that can be driven directly by a guide relay or remotely by the user. The board has 52 endpoints for I/O (input/output) purposes. For example, a series of terminal points are used for the C-shaped contacts of relay K20, including one terminal for the normally open position, one terminal for the common position, and one terminal for the normally closed position. In addition, the board is equipped with two plug-in connectors, CPH (positive power connector) and CPN (negative power connector), which provide a pluggable circuit control power supply. These connectors connect to the C1PL to C5PL and Y9PL to Y37PL pluggable circuits to provide positive and negative power control.

The DS200RTBAG3AHC board contains high energy when connected to the power supply, so extra care is required when operating to avoid safety risks. Before performing any maintenance or operation, it is necessary to follow procedures to disconnect all power supplies to ensure safety.

The product is widely used in industrial automation and control systems, especially in gas turbines or other large industrial equipment that require precise control and protection. Due to its high degree of flexibility and customizability, it is used in modern industrial fields, such as power, petroleum, mine lifting, ports, heating, gas, water supply, sewage treatment, metallurgy, paper making, textile, chemical, water conservancy and so on.

Input voltage: 12-24 VDC

Output voltage: 10-20 VAC

Output current: 100 mA

Operating temperature range: -40 to +70 °C

Dimensions: 100 x 50 x 25 mm

Weight: 0.5kg

Endpoints: 52 endpoints for I/O (input/output) purposes

Relays: 10 relays that can be driven directly by a guide relay or remotely by the user

Connectors: Two plug-in connectors CPH (positive power connector) and CPN (negative power connector) provide pluggable circuit control power

Pluggable circuits: C1PL to C5PL and Y9PL to Y37PL

Safety precautions: Because the board contains high energy, ensure that all power supplies are disconnected during operation to avoid safety risks
