工控备件NF93A-2 HESG440280R2自动化系统PLC模块

工控备件NF93A-2 HESG440280R2自动化系统PLC模块

IMHSS03模块的增强功能提高了其性能，优于其前身IMHSS01和IMHSS02模块。性能改进包括：高分辨率模数转换器和数模转换器，更精确的LVDT信号条件，I/H转换器接口，以及改进的数字和模拟输入/输出隔离。IMHSS03模块可以自动调整其解调器增益，提供更好的控制回路响应。

冗余LVDT接口可以处理交流或直流LVDT变压器。冗余伺服阀输出提供操作选择同时使用两个主动控制伺服阀或一个带有一个伺服阀的主动控制伺服阀备用物品本说明包含九节和五个附录。

安装或操作HSS之前，请阅读本文档单元本节内容概述如下。引言包含一般信息和技术规范。说明和活动使用方框图、示意图和文本解释模块安装包括为操作准备模块的初步步骤。

它包括开关设置、配置和现场接线。校准说明了如何校准模块和LVDT变压器，并在投入运行之前对控制回路进行调整。操作程序提供了有关日常使用、启动程序和正常操作。故障排除解释LED状况，列出状态消息，并列出出现问题时的纠正措施。

The IMHSS03 module's enhanced features improve its performance over its predecessor IMHSS01 and IMHSS02 modules. Performance improvements include: high-resolution analog-to-digital and digital-to-analog converters, more precise LVDT signal conditions, I/H converter interfaces, and improved digital and analog input/output isolation. The IMHSS03 module can automatically adjust its demodulator gain to provide better control loop response.

Redundant LVDT interfaces can handle AC or DC LVDT transformers. Redundant servo valve outputs provide operational options using two active control servo valves at the same time or one active control servo valve with one servo valve Spare Items This description contains nine sections and five appendices.

Before installing or operating HSS, read this section of the documentation unit as outlined below. The introduction contains general information and technical specifications. Instructions and activities Using block diagrams, diagrams, and text to explain module installation includes the initial steps to prepare the module for operation.

It includes switch setup, configuration and field wiring. Calibration explains how to calibrate the module and LVDT transformer and adjust the control loop before putting it into operation. The operating procedures provide information on daily use, startup procedures, and normal operation. Troubleshooting Explains LED conditions, lists status messages, and lists corrective actions when problems occur.
