通用电气接口模块板 DS200SIOBH1ACA带涂层耐高温接口板

通用电气接口模块板 DS200SIOBH1ACA带涂层耐高温接口板

DS200TCCBG1B 具有一个 80196 微处理器和多个 PROM 模块。它还包含一个 LED 和 2 个 50 针连接器。从电路板的侧视图可以看到 LED。50 针连接器的 ID 为 JCC 和 JDD。

该板还装有 3 个跳线。跳线在电路板表面印有 ID。ID 为 JP1、JP2 和 JP3。当原始电路板安装在驱动器中时，安装人员会配置电路板以地满足驱动器的要求。

跳线使安装人员能够通过更改跳线的位置来设置配置值。大多数情况下使用跳线的默认位置，安装人员无需采取进一步操作。但是，在某些情况下，安装人员会根据随电路板提供的印刷信息中的可用信息更改跳线的位置。  在 3 针跳线中，跳线一次覆盖 2 个针。

例如，跳线可能会覆盖引脚 1 和 2 或引脚 2 和 3。要移动跳线，请用拇指和食指抓住跳线并将其从引脚上拉下。然后，将跳线与新引脚对齐并将其滑入到位。有些跳线不用于配置板，只有一个支撑位置。在这种情况下，备用位置由制造商用于产品测试以测试特定电路或功能。

The DS200TCCBG1B has an 80196 microprocessor and multiple PROM modules. It also contains an LED and 2 50-pin connectors. The LED can be seen from the side view of the board. The ID of the 50-pin connector is JCC and JDD.

The board is also equipped with 3 jumpers. The jumper has an ID printed on the surface of the circuit board. The ids are JP1, JP2, and JP3. When the original board is installed in the driver, the installer configures the board to meet the driver's requirements.

Jumpers enable the installer to set configuration values by changing the location of the jumpers. In most cases, the default position of the jumper is used and no further action is required by the installer. However, in some cases, the installer will change the position of the jumper based on the information available in the printed information provided with the board. In a 3-pin jumper, the jumper covers 2 pins at a time.

For example, a jumper might cover pins 1 and 2 or pins 2 and 3. To move the jumper, grab the jumper with your thumb and forefinger and pull it off the pin. Then, align the jumper with the new pin and slide it into place. Some jumpers are not used for configuration boards and have only one support position. In this case, the alternate location is used by the manufacturer for product testing to test a specific circuit or function.
