IC200MDL742H 离散输出模块

IC200MDL742H 离散输出模块

IC200MDL742H离散输出模块是一个扩展模块，设计用于 Allen-Bradley ControlLogix® PLC（可编程逻辑控制器）系统。它提供 8 个高速分立输出通道，用于控制工业自动化应用中的开/关设备。

主要特点：

8 个离散输出通道：提供 8 个独立的离散输出通道，用于控制各种开/关设备。

高速开关：支持高达 10kHz 的高速开关速率，实现快速响应的控制。

非易失性存储器：即使在断电时也能存储配置参数，确保输出设置一致。

DIN导轨安装：支持DIN导轨安装，便于集成到控制面板和外壳中。

应用：

IC200MDL742H分立输出模块适用于需要高速分立控制的各种工业自动化应用，包括：

电机控制：控制电机的方向和速度。

电磁阀：控制电磁阀的开启和关闭。

指示灯：打开和关闭状态指示灯。

报警系统：激活警报和警报器。

继电器控制：控制外部继电器以执行各种开关任务。

好处：

增强的控制能力：实现对开/关设备的精确和响应式控制。

提高系统效率：优化控制性能和系统响应能力。

灵活的控制选项：适应各种离散控制需求。

运行可靠：确保可靠和一致的输出切换。

易于集成：支持DIN导轨安装，安装方便。

规格：

规范价值

离散输出通道 8

输出电压 24V 直流

输出电流 每通道 1.2A

开关速率 高达 10 kHz

非易失性存储器 是的

通讯接口 背板总线

电源 24V 直流

工作温度 -20°C 至 +60°C

尺寸（长 x 宽 x 高） 120 x 80 x 30 毫米

重量 0.3 千克

IC200MDL742H 离散输出模块

The IC200MDL742H discrete output module is an expansion module designed for use in Allen-Bradley ControlLogix® PLC (Programmable Logic Controller) systems. It provides eight high-speed discrete output channels for controlling on/off devices in industrial automation applications.

Main features:

Eight discrete output channels: Eight independent discrete output channels are provided to control various on/off devices.

High-speed switch: Support up to 10kHz high-speed switching rate, to achieve fast response control.

Non-volatile memory: Stores configuration parameters even when power is off, ensuring consistent output Settings.

DIN Rail mounting: Supports DIN rail mounting for easy integration into the control panel and housing.

Applications:

The IC200MDL742H discrete output module is suitable for a variety of industrial automation applications that require high speed discrete control, including:

Motor control: Control the motor's direction and speed.

Solenoid valve: Controls the opening and closing of the solenoid valve.

Indicator: On and off status indicator.

Alarm system: Activate alarms and sirens.

Relay control: Control external relays to perform various switching tasks.

Benefits:

Enhanced control: Precise and responsive control of on/off devices.

Improve system efficiency: Optimize control performance and system responsiveness.

Flexible control options: Adaptable to various discrete control needs.

Reliable operation: Ensures reliable and consistent output switching.

Easy integration: Support DIN rail installation, easy installation.

Specifications:

Normative value

Discrete output channel 8

Output voltage 24V DC

Output current 1.2A per channel

Switching speed up to 10 kHz

Non-volatile memory Yes

Communication interface backplane bus

Power supply 24V DC

Operating temperature -20°C to +60°C

Dimensions (L x W x H) 120 x 80 x 30 mm

Weight 0.3 kg
