概述

GE Fanuc IC694MDL646 是一款 16 通道数字输入模块，设计用于 RX3i PacSystem 系列可编程逻辑控制器 （PLC）。它是一种低压模块，可接受 24V 直流输入并提供正负逻辑。该模块具有紧凑的设计、坚固的结构和易于安装的特点，使其适用于广泛的工业自动化应用。

主要特点

• 16 个单独滤波和去抖动的输入：该IC694MDL646具有 16 个独立的输入通道，每个通道都有自己的滤波和去抖动电路。这确保了该模块能够抵抗噪声和误触发，从而提供可靠和准确的输入信号检测。

• 24V DC 额定电压：该模块设计用于 24V 直流输入信号，适用于广泛的工业应用。

• 正面或负面逻辑：该模块可以配置为正逻辑或负逻辑，使其与各种输入设备兼容。

• 高输入阻抗：每个输入通道都具有高输入阻抗，从而最大限度地减少了从所连接设备汲取的电流。这可以防止信号失真，并确保与各种输入源的兼容性。

• LED状态指示灯：每个输入通道都有一个 LED 指示灯，当输入处于活动状态时会亮起。这提供了输入状态的视觉指示，简化了故障排除和系统监控。

应用

• 按钮控制：该IC694MDL646可用于监控按钮、开关和其他手动控制设备的状态。

• 传感器接口：该模块可用于与各种传感器连接，例如接近传感器、限位开关和光电传感器，为过程控制或安全应用获取数据。

• 机器安全：该IC694MDL646可用于监控安全联锁、急停按钮和其他安全装置，确保机械设备的安全运行。

• 事件检测：该模块可用于检测事件，例如产品存在、输送机移动或开门、触发控制操作或提供状态信息。

• 通用数字输入：该IC694MDL646可用于各种工业自动化应用中的通用数字输入任务，例如监控机器状态、控制执行器和收集数据。

IC694MDL646  I/O 插槽中的输入模块

summarize

The GE Fanuc IC694MDL646 is a 16-channel digital input module designed for the RX3i PacSystem family of programmable logic controllers (PLCS). It is a low-voltage module that accepts 24V DC input and provides positive and negative logic. The module's compact design, robust construction and ease of installation make it suitable for a wide range of industrial automation applications.

Main feature

16 individually filtered and de-jitter inputs: The IC694MDL646 has 16 independent input channels, each with its own filtering and de-jitter circuits. This ensures that the module is resistant to noise and false triggers, providing reliable and accurate detection of the input signal.

24V DC rated voltage: The module is designed for 24V DC input signals and is suitable for a wide range of industrial applications.

Positive or negative logic: The module can be configured as positive or negative logic, making it compatible with various input devices.

High input impedance: Each input channel has a high input impedance, which minimizes the current drawn from the connected device. This prevents signal distortion and ensures compatibility with various input sources.

LED Status indicator: Each input channel has an LED indicator that lights up when the input is active. This provides a visual indication of the input status, simplifying troubleshooting and system monitoring.

Apply

Button control: The IC694MDL646 can be used to monitor the status of buttons, switches and other manually controlled devices.

Sensor interface: This module can be used to connect with a variety of sensors, such as proximity sensors, limit switches and photoelectric sensors, to acquire data for process control or safety applications.

Machine safety: The IC694MDL646 can be used to monitor safety interlocks, scram buttons and other safety devices to ensure the safe operation of machinery.

Event detection: This module can be used to detect events such as product presence, conveyor movement or opening, triggering control operations, or providing status information.

Universal digital input: The IC694MDL646 can be used for common digital input tasks in a variety of industrial automation applications, such as monitoring machine status, controlling actuators, and collecting data.
