IC694ALG221 接触器安全处理器

IC694ALG221 接触器安全处理器

IC694ALG221 接触器安全处理器
IC694ALG221是 PACSystem RX3i 可编程自动化控制器 （PAC） 的组件模块。该模块具有四 （4） 个模拟输入通道，旨在接受电流输入信号，例如 0-20 mA 和 4-20 mA 电气标准。该模块用于连接模拟测量仪器，如变送器、信号分配器、隔离器、转换器和类似设备，用于监控和实现模拟系统的闭环控制。该IC694ALG221具有内置模数转换器 （DAC） 电路，可将模拟数据转换为主机控制器可读取的数字格式，以便进行处理、调节和集成到用户逻辑中。ADC输出在4-20mA时的分辨率为4 μA，在0-20 mA时的分辨率为5 μA，绝对精度为0.1%满量程+0.1%读数。每个输入通道的更新速率为 2 ms，工厂校准为每次计数 4 μA。该模块具有 200 伏的共模电压和 < 1 个最低有效位 （LSB） 的线性度。它具有场到背板（光学）隔离，并且连续电压为 250 VAC 和 1500 VAC 持续 1 分钟的框架接地隔离。该模块的输入滤波器响应为 325 Hz，而输入阻抗为 250 Ω。该模块的内部额定功耗为100 mA（隔离式24 VDC电源），25 mA（PLC背板上的+5VDC总线）的额定功耗。该模块带有一个 MODULE OK LED，前提是用户指示该模块已主动供电。

GE Fanuc IC694ALG221 输入模块是一个具有 4 个输入点的模拟电流输入模块。它与 GE RX3i PacSystems 产品线中制造的每个 CPU 兼容。该模块是可热插拔的，这意味着它可以插入或拔出通电的GE背板。尝试热插拔IC694ALG221输入模块可能会导致组件损坏和用户伤害。

GE Fanuc RX3i PacSystems IC694ALG221来自背板的 4 点模拟汲取电流。在 5 伏直流电压下，该模拟输入模块可支持 25 毫安或 0.125 瓦的负载。在 24 伏直流隔离电压下，该输入模块可支持 100 毫安或 2.4 瓦的负载。IC694ALG221输入模块还可以在 2 个不同的输入电流范围下工作，分别为 4 至 20 毫安和 0 至 20 毫安。该模块带有一个用于输入通道 1 和 2 的范围跳线，以及另一个用于输入通道 3 和 4 的范围跳线。每个通道的转换速度为半毫秒。模块上有 1 个绿色 LED，称为模块正常 LED，当模块通电时会亮起。

IC694ALG221 接触器安全处理器

The IC694ALG221 is a component module of the PACSystem RX3i Programmable Automation Controller (PAC). The module has four (4) analog input channels designed to accept current input signals, such as 0-20 mA and 4-20 mA electrical standards. The module is used to connect analog measuring instruments such as transmitters, signal splitters, isolators, converters and similar devices for monitoring and closed-loop control of analog systems. The IC694ALG221 has a built-in analog-to-digital converter (DAC) circuit that converts analog data into a digital format that can be read by the host controller for processing, conditioning, and integration into user logic. The ADC output has a resolution of 4 μA at 4-20mA and 5 μA at 0-20 mA, with an absolute accuracy of 0.1% full scale +0.1% reading. The update rate is 2 ms per input channel, factory-calibrated to 4 μA per count. The module has a common mode voltage of 200 volts and linearity of < 1 least significant bit (LSB). It has field-to-backplane (optical) isolation and frame-ground isolation with continuous voltages of 250 VAC and 1500 VAC for 1 minute. The module has an input filter response of 325 Hz and an input impedance of 250 Ω. The module has an internal power rating of 100 mA (isolated 24 VDC power supply) and 25 mA (+5VDC bus on the PLC backplane). The MODULE comes with a MODULE OK LED, provided the user indicates that the module is actively powered.

The GE Fanuc IC694ALG221 input module is an analog current input module with 4 input points. It is compatible with every CPU manufactured in the GE RX3i PacSystems product line. The module is hot-swappable, meaning it can be plugged in or pulled out of a powered GE backplane. Attempts to hot-swap the IC694ALG221 input module may result in component damage and user injury.

GE Fanuc RX3i PacSystems IC694ALG221 4-point analog draw current from the backplane. At 5 volts DC, the analog input module can support loads of 25 mA or 0.125 watts. At 24 volts DC isolation, the input module can support a load of 100 mA or 2.4 watts. The IC694ALG221 input module can also operate in 2 different input current ranges of 4 to 20 mA and 0 to 20 mA. The module comes with a range jumper for input channels 1 and 2, and another range jumper for input channels 3 and 4. The conversion speed for each channel is half a millisecond. There is a green LED on the module, called the module normal LED, which lights up when the module is powered on.
