IC693ALG223 中央处理器带2个串行端口需要外部高容量电池

IC693ALG223 中央处理器带2个串行端口需要外部高容量电池

IC693ALG223是一个中央处理器模块，带有 2 个串行端口，用于 GE Fanuc 90-30 系列 PLC。它作为PLC系统的中央处理单元，负责执行控制逻辑、管理通信和提供整体系统控制。此外，它还具有两个串行端口，用于连接外部设备和网络。

IC693ALG223中央处理器模块的主要特点：

• 32 位 RISC 处理器：该IC693ALG223采用 32 位 RISC（精简指令集计算机）处理器，为要求苛刻的控制应用提供充足的处理能力。

• 板载内存：它包括用于存储控制程序、配置数据和特定应用数据的板载存储器。

• Genius 通信协议：该模块利用 Genius 通信协议与其他 Genius I/O 模块进行通信，确保系统内高效的数据交换。

• 两个串行端口：它提供两个串行 RS-232C 端口，用于连接外部设备，例如 HMI、打印机和条形码扫描仪。

• 外接备用电池：IC693ALG223需要外部高容量电池，以在断电时维护系统内存和时钟数据。

• 诊断 LED：状态 LED（INT PWR LED、OK LED 和 TX/RX LED）分别指示输入电源的存在、模块的正常运行和通信状态。

IC693ALG223 中央处理器带2个串行端口需要外部高容量电池

The IC693ALG223 is a central processing unit module with 2 serial ports for GE Fanuc 90-30 series PLC. It acts as the central processing unit of the PLC system and is responsible for executing control logic, managing communications and providing overall system control. In addition, it has two serial ports for connecting external devices and networks.

Main features of IC693ALG223 CPU module:

32-bit RISC Processor: The IC693ALG223 uses a 32-bit RISC (Reduced Instruction Set Computer) processor to provide sufficient processing power for demanding control applications.

Onboard memory: It includes onboard memory for storing control programs, configuration data, and application-specific data.

Genius Communication Protocol: The module uses the Genius communication protocol to communicate with other Genius I/O modules, ensuring efficient data exchange within the system.

Two serial ports: It provides two serial RS-232C ports for connecting external devices such as Hmis, printers, and barcode scanners.

External backup battery: IC693ALG223 requires an external high-capacity battery to maintain system memory and clock data in the event of a power outage.

Diagnostic leds: Status leds (INT PWR LED, OK LED, and TX/RX LED) indicate the presence of input power, normal operation of the module, and communication status, respectively.
