IC687BEM713是 GE Fanuc（现为 Emerson Automation）的 Genius I/O 系列中的总线扩展模块。它旨在通过添加额外的 I/O 模块或通信模块来扩展 Genius I/O 机架的通信功能。这允许在单个 I/O 系统中容纳更多的 I/O 点和通信选项。

IC687BEM713总线扩展器模块的主要特性：

• 扩展 I/O 容量：该IC687BEM713可以向 Genius I/O 机架添加多达 32 个额外的 I/O 模块或通信模块，从而显著提高系统的 I/O 容量。

• 配置灵活：它支持各种 I/O 模块和通信模块，可灵活满足各种应用需求。

• 点对点通信：该模块利用 Genius I/O 机架与扩展的 I/O 模块或通信模块之间的点对点通信，确保可靠的数据传输。

• 背板配电：它将电源从 Genius I/O 机架分配到连接的 I/O 模块或通信模块，无需单独的电源。

• 诊断 LED：状态 LED（INT PWR LED、OK LED 和 TX/RX LED）分别指示输入电源的存在、模块的正常运行和通信状态。

IC687BEM713总线扩展器模块的应用：

• 大规模 I/O 系统：该IC687BEM713通常用于需要大量 I/O 点的大型 I/O 系统，例如制造工厂、过程控制系统和基础设施控制系统。

• 分布式 I/O 系统：它可用于分布式 I/O 系统，其中 I/O 块位于远离中央控制器的位置，从而实现灵活的 I/O 布局并降低布线成本。

• 模块化机器控制系统：该模块适用于模块化机器控制系统中的应用，其中 I/O 要求可能因特定机器配置而异。

• 改造和扩建项目：它可用于改造和扩展项目，为现有 Genius I/O 系统增加 I/O 容量，而无需完全更换系统。

使用IC687BEM713的注意事项：

• I/O 要求：仔细评估应用程序的 I/O 要求，以确定要连接的 I/O 块或通信模块的适当数量。

• 电缆长度：考虑 Genius I/O 机架与扩展的 I/O 模块或通信模块之间的电缆长度，以确保可靠的通信。

• 功耗：评估连接的 I/O 模块或通信模块的功耗，以确保 Genius I/O 机架的电源能够处理负载。

• 通讯协议：利用 Genius 通信协议将IC687BEM713连接到 Genius I/O 机架和扩展的 I/O 模块或通信模块。

• 专家支持：对于专门的配置、安装或故障排除任务，请向合格的 GE Fanuc（现为 Emerson Automation）人员或授权经销商寻求帮助。

IC687BEM713 总线发送器模块

The IC687BEM713 is a bus expansion module in the Genius I/O family of GE Fanuc (now Emerson Automation). It is designed to extend the communication capabilities of the Genius I/O rack by adding additional I/O modules or communication modules. This allows more I/O points and communication options to be accommodated in a single I/O system.

Main features of the IC687BEM713 bus extender module:

Expanding I/O capacity: The IC687BEM713 can add up to 32 additional I/O modules or communication modules to the Genius I/O rack, significantly increasing the system's I/O capacity.

Flexible configuration: It supports a variety of I/O modules and communication modules, which can flexibly meet various application requirements.

Point-to-point communication: This module utilizes point-to-point communication between Genius I/O racks and extended I/O modules or communication modules to ensure reliable data transfer.

Backplane power distribution: It distributes power from the Genius I/O rack to connected I/O modules or communication modules without the need for a separate power supply.

Diagnostic leds: Status leds (INT PWR LED, OK LED, and TX/RX LED) indicate the presence of input power, normal operation of the module, and communication status, respectively.

Application of IC687BEM713 bus extender module:

Large-scale I/O systems: The IC687BEM713 is commonly used in large I/O systems that require a large number of I/O points, such as manufacturing plants, process control systems, and infrastructure control systems.

Distributed I/O systems: It can be used in distributed I/O systems where I/O blocks are located away from the central controller, enabling flexible I/O layout and reducing cabling costs.

Modular machine Control Systems: This module is suitable for applications in modular machine control systems where I/O requirements may vary depending on the particular machine configuration.

Retrofit and Expansion projects: It can be used for retrofit and expansion projects to add I/O capacity to an existing Genius I/O system without the need to completely replace the system.

Precautions for using IC687BEM713:

I/O requirements: Carefully evaluate the application's I/O requirements to determine the appropriate number of I/O blocks or communication modules to connect.

Cable length: Consider the length of the cable between the Genius I/O rack and the extended I/O module or communication module to ensure reliable communication.

Power consumption: Evaluate the power consumption of the connected I/O module or communication module to ensure that the power supply of the Genius I/O rack can handle the load.

Communication protocol: Connect the IC687BEM713 to the Genius I/O rack and extended I/O modules or communication modules using the Genius communication protocol.

Expert Support: For specialized configuration, installation, or troubleshooting tasks, seek help from a qualified GE Fanuc (now Emerson Automation) personnel or authorized resellers.
