FBM233 现场设备系统集成模块10/100 Mbps以太网冗余

FBM233 现场设备系统集成模块10/100 Mbps以太网冗余

FBM233输出模块PLC控制系统,综合抗干扰设计FLEX数字量I/O模块按其功能可以分为带保护输出型、带电子保险型、带自诊断

型和隔离型。

(1)带保护输出型:具有电子保护,能够在短路、过载或过热情况下切断输出,在输出故障排除时自动恢复。没有故障状态信息提供给处理器,模块型号末尾为P。

(2)带电子保险型:能够在故障发生时断开输出,通过操作按钮、软件或输入重新通电复位“保险”。故障状态信息提供给处理器,模块型号末尾为EP。

(3)带自诊断型:能够检测、指示并报告给处理器如下故障:现场输入或输出设备开路或接线开路;现场设备输出短路;输入或输出接线短路;用户电源接线反极性。模块型号末尾为D。

(4)隔离型:内部I/O通道间相互隔离,模块型号末尾为1。

FBM 233，10/100 MBPS以太网，冗余，部件号P0926GX

特征

FBM233的主要特点是:

-进出现场设备的冗余10 Mbps或100 Mbps以太网网络传输速率

-与多达64个现场设备通信

-I/O软件驱动程序可从可用协议库中下载

-多达2000个DCI块连接

-使用以太网连接将现场设备数据集成到I/A系列控制数据库中

-现场安装

-G3级(恶劣)环境。

FBM233 现场设备系统集成模块10/100 Mbps以太网冗余

FBM233 output module PLC control system, integrated anti-interference design FLEX digital I/O module according to its function can be divided into with protection output type, with electronic insurance type, with self-diagnosis

Type and isolation type.

(1) With protected output type: with electronic protection, it can cut off the output in the case of short circuit, overload or overheating, and automatically recover when the output is troubleshooting. No fault status information is provided to the processor, and the module model end is P.

(2) With electronic insurance type: can disconnect the output when the fault occurs, and reset the "insurance" by operating the button, software or input re-energizing. The fault status information is provided to the processor. The end of the module model is EP.

(3) With self-diagnosis: can detect, indicate and report to the processor the following faults: field input or output device open circuit or wiring open circuit; Field equipment output short circuit; The input or output wiring is short-circuited; Reverse polarity of the user power cable. The end of the module model is D.

(4) Isolation type: The internal I/O channels are isolated from each other, and the end of the module model is 1.

FBM 233, 10/100 MBPS Ethernet, redundant, part number P0926GX

trait

The main features of the FBM233 are:

- Redundant 10 Mbps or 100 Mbps Ethernet network transfer rates in and out of field devices

- Communicate with up to 64 field devices

-I/O software drivers can be downloaded from the available protocol library

- Up to 2000 DCI block connections

- Use Ethernet connectivity to integrate field device data into I/A series control databases

- On-site installation

- Level G3 (Harsh) environment.
