FOXBORO SY-0301059F SY-1025115C/SY-1025120E全新到货PLC自动化备件

FOXBORO SY-0301059F SY-1025115C/SY-1025120E全新到货PLC自动化备件

MB86S02视频图像传感器在FPGA的控制下进行视频图像信息的采集，在收到PC机的采集命令后MB86S02开始视频信号的采集 FPGA作为系统的核心控制单元不仅负责视频图像的采集，而且负责视频图像信息的预处理和系统各单元模块之间的数据交互。

针对视频图像数据量大的特点，为了保证系统的实时性要求，系统采用大容量的片外SDRAMR对采集到的视频图像信息进行缓存，SDRAM控制器由FPGA实现，视频图像信息经过 SDRAM缓存后首先要由FPGA对其进行滤波处理，以消除图像信息中的噪声干扰，本系统中采用中值滤波的方式对采集到的视频信息进行处理，滤波后的数据通过FPGA内部FIFO进入DSP进行下一步的压缩处理。

DSP上电后首先进行引导程序的自加载，等待FPGA发送请求，在收到FPGA的请求后，DSP建立EDMA通道从FPGA获取视频数据，存满一帧后，开始对视频图像进行JPEG压缩处理，压缩处理后的视频图像信息经过FIFO缓存后，在 FPGA的控制下写入USB接口控制器的数据缓存区，等待PC机的读数请求，USB接口控制器在收到PC机的读数请求后将数据写入PDIUSBD12的端口1，以便PC机下一步读取数据。
