A6500-UM通用测量卡是AMS 6500 ATG的一个组件机械保护系统。该卡配有2个传感器输入通道(独立或组合，根据所选择的测量模式)与大多数工作

常见的传感器如涡流、压电(加速度计或速度计)、地震(电动力学)，LF(低频轴承振动)，霍尔效应和LVDT (in结合A6500-LC)传感器。除此之外，该卡还包含5个数字输入6个数字输出。

测量信号通过内部RS传输485总线到A6500-CC Com卡，转换为Modbus RTU和Modbus TCP/用于进一步传输到主机或分析系统的IP协议。此外,Com卡通过面板上的USB接口提供通信用于连接到PC/笔记本电脑的配置卡和可视化测量结果。

此外，测量结果可以通过模拟输出0/4 - 20 mA。这些输出有一个共同的接地和电与系统电源隔离。A6500-UM通用测量仪的操作卡在A6500-SR系统机架中执行，该系统机架还提供连接供电电压和信号。

A6500-UM EMERSON 通用测量卡 设备保护系统组件

The A6500-UM Universal Measurement card is a component mechanical protection system of the AMS 6500 ATG. The card is equipped with 2 sensor input channels (independent or combined, depending on the selected measurement mode) for most work

Common sensors such as eddy current, piezoelectric (accelerometer or speedometer), seismic (electrodynamics), LF(low frequency bearing vibration), Hall effect and LVDT (in combined with A6500-LC) sensors. In addition, the card also contains 5 digital inputs and 6 digital outputs.

The measurement signal is transmitted via the internal RS 485 bus to the A6500-CC Com card, converted into Modbus RTU and Modbus TCP/ IP protocols for further transmission to the host or analysis system. In addition, the Com card provides communication through the USB interface on the panel for connecting to the PC/ laptop configuration card and visualizing the measurement results.

In addition, the measurement results can be output 0/4-20 mA by analog. These outputs have a common ground and are electrically isolated from the system power supply. Operation of the A6500-UM universal measuring instrument is performed in the A6500-SR system rack, which also provides connection supply voltage and signal.
