EDS-408A-MM-SC 工业以太网交换机

EDS-408A-MM-SC 工业以太网交换机

EDS-408A-MM-SC工业以太网交换机是一款专为工业应用设计的网络设备。它具备多项功能，适用于各种严苛的工业环境。以下是关于EDS-408A-MM-SC工业以太网交换机的详细介绍：

产品特点：

入门级8端口工业级以太网交换机，专为工业应用设计。

支持多项网管功能，如MOXA Turbo Ring、ring coupling、VLAN、QoS、RMON、频宽管理、port mirroring及自动e-mail或Relay输出警告等。

使用者可通过web-based管理界面及DIP Switch简易设定Turbo Ring冗余环网。

强韧的硬件设计，适用于各种严竣的工业环境。

具备工业级可靠度及网络冗余功能，安全特性符合IEC 62443标准。

符合多种行业认证，如轨道应用的EN 50155标准、电力自动化系统的IEC 61850-3标准、智能运输系统的NEMA TS2等。

端口与连接：

端口类型包括6个10/100BaseT(X)(RJ-45)和2个100BaseFX端口（多模，SC接头）。

端口数量共8口。

网络标准与功能：

支持IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.1D-2004等网络标准。

提供VLAN功能，包括802.1Q VLAN、GMRP、GVRP、IGMP等。

支持环网冗余功能，如RSTP、STP、Turbo Chain、Turbo Ring等。

还具备Back Pressure Flow Control等网管功能。

电源与尺寸：

电压为24VDC冗余双电源输入。

尺寸为53.6135105mm。

总的来说，EDS-408A-MM-SC工业以太网交换机是一款功能丰富、性能稳定的网络设备，适用于各种需要高可靠性和稳定性的工业应用场景。无论是自动化生产线、能源管理系统还是智能运输系统，它都能提供可靠的数据传输和网络控制，确保工业环境的顺畅运行。

请注意，具体的产品参数和价格可能因供应商和地区差异而有所不同。在购买前，建议与供应商或制造商联系，以获取最新的产品信息、价格以及技术支持。同时，为确保网络的安全性和稳定性，使用时请遵循相关的安装、配置和维护指南。

EDS-408A-MM-SC 工业以太网交换机

The EDS-408A-MM-SC Industrial Ethernet switch is a networking device designed for industrial applications. It has multiple functions and is suitable for a variety of harsh industrial environments. The following is a detailed introduction to the EDS-408A-MM-SC Industrial Ethernet switch:

Product features:

Entry-level 8-port industrial Ethernet switch designed for industrial applications.

Supports multiple network management functions, such as MOXA Turbo Ring, ring coupling, VLAN, QoS, RMON, bandwidth management, port mirroring, and automatic e-mail or Relay output warning.

Users can easily configure the Turbo Ring redundant ring network through the web-based management interface and DIP Switch.

Strong hardware design, suitable for a variety of tough industrial environments.

With industrial-grade reliability and network redundancy, safety features comply with IEC 62443 standards.

It complies with various industry certifications, such as EN 50155 for rail applications, IEC 61850-3 for power automation systems, NEMA TS2 for intelligent transportation systems, etc.

Ports and connections:

Port types include six 10/100BaseT(X)(RJ-45) and two 100BaseFX ports (multi-mode, SC connector).

Number of ports A total of eight ports are available.

Network Standards and Features:

Supports IEEE 802.3, IEEE 802.3U, IEEE 802.3x, IEEE 802.1D-2004 and other network standards.

Provides VLAN functions, including 802.1Q VLAN, GMRP, GVRP, and IGMP.

Supports Ring network redundancy, such as RSTP, STP, Turbo Chain, and Turbo Ring.

It also has Back Pressure Flow Control and other network management functions.

Power Supply and size:

The voltage is 24VDC with redundant dual power inputs.

The size is 53.6135105mm.

Overall, the EDS-408A-MM-SC Industrial Ethernet switch is a feature-rich, stable networking device for a variety of industrial applications that require high reliability and stability. Whether it is automated production lines, energy management systems or intelligent transportation systems, it provides reliable data transmission and network control to ensure the smooth operation of industrial environments.

Please note that specific product parameters and prices may vary by supplier and region. Before purchasing, it is recommended to contact the supplier or manufacturer for the latest product information, pricing, and technical support. To ensure network security and stability, follow the related installation, configuration, and maintenance guidelines.
