95UVS2-1 Fireye 紫外线集成火焰扫描仪

95UVS2-1 Fireye 紫外线集成火焰扫描仪

FIREYE InSight 系列的95IR、 95UV和 95DS型火焰检测器是基于微处理器设计的火焰探头， 使用固态的红外线传感器（IR）、紫外传感器（UV）或双传感器（IR和UV）。 此系列火检探头均带有内部火焰继电器，ON/OFF门槛值可调，因此不需远程放大器。 InSight系列检测器可完美替换FIREYE 45FS1 和 45UVFS1系列探头，以及45RM4系列探头， 可以检测单燃烧器或多燃烧器工况下目标火焰的有或无。 InSight探头检测目标火焰产生的调制振幅（即火焰的闪烁特性）。在探头的设定程序中，将 会选择调制频率，这个数值会直接影响到最佳的火焰识别能力（ON/OFF值）。并可手动设 定（S1型）或越过手动设定进行自动设定（S2型）来选择合适的调制频率和探头增益。 InSight 95IR、 95UV和 95DS 探头，每种都因功能的不同而被分为两种型号。 标准型S1, 有三种火焰闪烁频率可选择，传感器增益可调，火焰继电器ON/OFF门槛值可调， 4-20mA模拟信号强度输出，故障继电器输出，2个可选编程文件来存储设定值（用于两种不 同的燃料或燃料比率）。 扩展型S2, 增加了带有手动旁通的自动编程（自动设定）功能，21个火焰闪烁频率可选，共4 个可选择的编程文件来存储设定值，还增加了通过用Fireye基于Windows95/98/NT的用户应 用软件的远程通讯功能。 所有 FIREYE InSight 探头均需要24 Vdc电源，有电子自检功能（不需机械快门），设有可显 示8位字母数字LED屏和4个按钮式小键盘使用户可以查看运行参数和选择设定值。 “CG” 型号的探头包括一根10英尺（3米）长的自带电缆和电缆密封件。非“CG”型号 的探头的电缆则是12针快拆接头连接。也有可以连接光纤的型号。请参看CU-101手册中的 安装说明。

95UVS2-1 Fireye 紫外线集成火焰扫描仪

The FIREYE InSight series 95IR, 95UV, and 95DS flame detectors are microprocessor-based flame probes that use solid-state infrared sensors (IR), ultraviolet sensors (UV), or dual sensors (IR and UV). This series of fire detectors are equipped with internal flame relays and adjustable ON/OFF thresholds, so no remote amplifier is required. The InSight series detectors are a perfect replacement for the FIREYE 45FS1 and 45UVFS1 series probes, as well as the 45RM4 series probes, which can detect the presence or absence of a target flame in single or multi-burner conditions. The InSight probe detects the modulated amplitude (i.e. the flicker properties of the flame) generated by the target flame. In the probe setup program, the modulation frequency is selected, and this value directly affects the best flame recognition capability (ON/OFF value). It can also be set manually (type S1) or automatically set beyond the manual setting (type S2) to select the appropriate modulation frequency and probe gain. The InSight 95IR, 95UV and 95DS probes are each divided into two models for different functions. Standard S1, with three flame flicker frequency options, adjustable sensor gain, adjustable flame relay ON/OFF threshold, 4-20mA analog signal strength output, fault relay output, 2 optional programming files to store setpoints (for two different fuels or fuel ratios). The extended S2 adds automatic programming (automatic setting) with manual bypass, 21 flame flicker frequency selectable, a total of 4 selectable programming files to store set values, and adds remote communication with Fireye based Windows95/98/NT user software. All FIREYE InSight probes require a 24 Vdc power supply, have an electronic self-test function (no mechanical shutter required), feature an 8-digit alphanumeric LED display and four push-button keypadlets that allow users to view operating parameters and select Settings. The "CG" model probe includes a 10-foot (3 m) cable and cable seal. The cable for non-CG models is a 12-pin quick-release connector connection. There are also models that can connect optical fibers. Refer to the installation instructions in the CU-101 manual.
