HONEYWELL霍尼韦尔CC-PCF901控制防火墙模块 集成系统处理器模块

HONEYWELL霍尼韦尔CC-PCF901控制防火墙模块 集成系统处理器模块

HONEYWELL CC-PCF901 VMIVME-7455与VMIVME-7591、-7592或-7695的安装是：与前几页的安装类似。唯一的例外是VMIVME-7695是与VME64兼容的产品。建议：VMIVME-7455和VMIVME-7695可用于标准VMEbus机箱。

但是，如果需要使用VME64机箱，VME64背板将使用：160引脚5行连接器，其中只有背板引脚的中心三行用于信号、电源和接地。因此VMIVME-7455在VME64机箱中，必须小心确保正确的对齐使用第9页图4所示的64芯电缆组件，以：通过将CPU板连接到CD ROM和可选的VMIVME-7452背板。

两种电缆应使用相同的64芯电缆组件VMEbus和VME64背板。接口电缆零件号为VMIC型号编号：VMIVME-VMXC-3。本节提供了与VMIC的保养和维护相关的信息产品。

The installation of the HONEYWELL CC-PCF901 VMIVME-7455 with the VMIVME-7591, -7592, or -7695 is: similar to the installation on the previous pages. The only exception is that VMIVME-7695 is compatible with VME64. Recommendation: The VMIVME-7455 and VMIVME-7695 can be used in standard VMEbus chassis.

However, if a VME64 chassis is required, the VME64 backplane will use: 160 pin 5-row connectors, where only the center three rows of the backplane pins are used for signal, power, and ground. Therefore VMIVME-7455 In the VME64 chassis, care must be taken to ensure proper alignment using the 64-core cable assembly shown in Figure 4 on page 9 to: by connecting the CPU board to the CD ROM and the optional VMIVME-7452 backplane.

Both cables should use the same 64-core cable assembly VMEbus and VME64 backplane. The part number of the interface cable is VMIC model number: VMIVME-VMXC-3. This section provides information products related to the care and maintenance of VMIC.
