SPS5710 51199929-100PI模块包括三个隔离的输入通道。每个输入通道独立处理输入到模块的所有数据，并将数据传递给主处理器，主处理器对数据进行投票，以确保的完整性。

每个模块在每个通道上提供持续诊断。任何通道上的任何诊断故障都会故障指示灯，进而底盘报警信号。故障指示灯仅指示通道故障，而不是模块故障。SPS5710 51199929-100模块在出现单一故障时能够正常运行，并且在出现某些类型的多个故障时能够继续正常运行。脉冲输入模块支持热备用模块。

警告：PI模块不提供累加功能，SPS5710 51199929-100是为测量旋转设备的速度而优化的。对于3515型脉冲累加，继电器输出模块3636R/T型继电器输出（RO）模块是一种非三重模块，用于与“固态输出开关不兼容的非关键点。

一个例子是与信号器面板接口。继电器输出模块在三个通道中的每个通道上接收来自主处理器的输出信号。然后对这三组信号进行表决，表决后的数据用于驱动32个单独的继电器。每个输出都有一个环回电路，该电路独立于负载的存在来验证每个继电器开关的操作，SPS5710 51199929-100同时进行诊断以测试模块的操作状态。任何诊断故障都会故障指示灯，进而底盘警报。

The SPS5710 51199929-100PI module includes three isolated input channels. Each input channel independently processes all data entered into the module and passes the data to the main processor, which votes on the data to ensure its integrity.

Each module provides continuous diagnostics on each channel. Any diagnostic fault on any channel will result in a fault indicator light, which in turn will signal the chassis alarm. The fault indicator indicates only channel failure, not module failure. The SPS5710 51199929-100 module is capable of operating normally in the event of a single failure and continues to operate normally in the event of multiple failures of some types. The pulse input module supports the hot standby module.

Warning: PI module does not provide accumulation function, SPS5710 51199929-100 is optimized for measuring the speed of rotating equipment. For type 3515 pulse accumulation, the Relay output module Type 3636R/T Relay Output (RO) module is a non-triple module for non-critical points incompatible with "solid state output switches."

One example is the interface to the signaler panel. The relay output module receives the output signal from the autonomous processor on each of the three channels. These three sets of signals are then voted on, and the data after the vote is used to drive 32 individual relays. Each output has a loopback circuit that verifies the operation of each relay switch independent of the presence of a load, while SPS5710 51199929-100 performs diagnostics to test the operating status of the module. Any diagnostic fault will cause a fault indicator, which in turn will alarm the chassis.
