5AP933.215C-00 自动化面板 贝加莱品牌"B&R "触摸屏

5AP933.215C-00 自动化面板 贝加莱品牌"B&R "触摸屏

B&R 5AP933.215C-00 自动化面板 是一款触摸屏显示设备，通常用于工业自动化和控制系统中。这款设备由全球工业技术领导者ABB设计，并以其卓越的性能和效率而著称。

技术规格：

显示尺寸：15英寸

分辨率：1024 x 768 像素

显示颜色：262,144色

显示类型：TFT彩色

显示亮度：350 cd/m²

触摸屏类型：电容式触摸屏，支持多点触控

外形尺寸：385 x 304 x 61 mm

重量：5.5 kg

电源电压：24 VDC

电源功耗：约 50 W

连接方式：DVI-I, USB, 以太网

工作温度范围：0°C 到 50°C

存储温度范围：-20°C 到 60°C

防护等级：IP65

应用：

B&R 5AP933.215C-00 自动化面板主要用于监视和显示过程数据、控制系统状态和其他相关信息。它配备了触摸屏界面，允许操作人员使用触摸操作来交互和控制系统。此外，这款面板具有高分辨率显示，为操作人员提供清晰、准确的视觉体验。

总结：

B&R 5AP933.215C-00 自动化面板是一款功能强大、性能卓越的触摸屏显示设备，适用于各种工业自动化和控制系统。其高分辨率显示和电容式触摸屏设计使得操作更加便捷和直观。此外，该设备还具有广泛的连接选项和强大的防护等级，确保其在各种环境下都能稳定运行。

5AP933.215C-00 自动化面板 贝加莱品牌"B&R "触摸屏

The B&R 5AP933.215C-00 Automation Panel is a touch screen display device commonly used in industrial automation and control systems. The device was designed by ABB, the global industrial technology leader, and is known for its superior performance and efficiency.

Technical specifications:

Display size: 15 inches

Resolution: 1024 x 768 pixels

Display color: 262,144 colors

Display type: TFT color

Display brightness: 350 cd/m²

Touch screen type: Capacitive touch screen, support multi-touch

Overall dimensions: 385 x 304 x 61 mm

Weight: 5.5kg

Power supply voltage: 24 VDC

Power consumption: about 50 W

Connection mode: DVI-I, USB, Ethernet

Operating temperature range: 0°C to 50°C

Storage temperature range: -20°C to 60°C

Protection class: IP65

Applications:

The B&R 5AP933.215C-00 Automation panel is mainly used to monitor and display process data, control system status and other relevant information. It is equipped with a touch screen interface that allows operators to interact and control the system using touch operations. In addition, the panel features a high-resolution display that provides the operator with a clear, accurate visual experience.

In SUMMARY:

The B&R 5AP933.215C-00 Automation Panel is a powerful, high-performance touch screen display for a wide range of industrial automation and control systems. Its high-resolution display and capacitive touch screen design make operation more convenient and intuitive. In addition, the device has a wide range of connectivity options and a robust level of protection, ensuring stable operation in a variety of environments.
